Confidential
Until:
1 Aug 2018
20
T
Q
BJ
213
8
20
D:\PSG\Amalina PSG job\AKX710 GS data\AKX710 GS TQBJ2138 EN.fm
Specifications
█
General
Dimensions (W x H x D)
458 mm x
137
mm x 341
mm
Mass (SA-AKX710)
4.0 k
g
Operating temperature range
0°C to +40°C
Operating humidity range
35% to 80% RH (no condensation)
█
Amplifier section
RMS output power stereo mode
Front Hi (both ch driven)
500 W per channel (2
Ω
), 1 kHz, 30% THD
Front Lo (both ch driven)
500 W per channel (2
Ω
), 100 Hz, 30% THD
Total RMS stereo mode power
2000 W
PMPO output power
22000 W
█
Tuner section
Frequency modulation (FM)
Preset memory
30 stations
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals
75
Ω
(unbalanced)
Amplitude modulation (AM)
Preset memory
15 stations
Frequency range
522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
█
Disc section
Disc played (8 cm or 12 cm)
CD, CD-R/RW (CD-DA, MP3 )
MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength
790 nm (CD)
█
Terminal section
USB port
USB standard
USB 2.0 full speed
Media file format support
MP3 (
*
.mp3)
USB device file system
FAT12, FAT16, FAT32
USB recording
Bit rate
128 kbps
USB recording speed
1x, 3x (CD only)
Recording file format
MP3 (
*
.mp3)
AUX
Audio input
Pin jack (1 system)
Microphone
Terminal
Mono, 6.3 mm jack (2 systems)
█
Internal memory section
Memory
Memory size
4 GB
Media file format support
MP3 (
*
.mp3)
Memory recording
Bit rate
128 kbps
Memory recording speed
1x, 3x (CD only)
Recording file format
MP3 (
*
.mp3)
█
Bluetooth
®
section
Version
Bluetooth
®
Ver. 2.1 + EDR
Class
Class 2
Supported profiles
A2DP, AVRCP, SPP, OPP, FTP
Operating frequency
2.4 GHz band FH-SS
Frequency band
2402 MHz to 2480 MHz
Maximum power (EIRP)
4 dBm
Operation distance
10 m line of sight
Supported codec
SBC
█
Speaker section
Speaker unit(s)
Super Woofer
20 cm cone type
Woofer
8 cm cone type
Tweeter
6 cm cone type
Impedance
High 2
Ω
/ Low 2
Ω
Dimensions (W x H x D)
313 mm x 425 mm x 264 mm
Mass
6.9 k
g
Note:
•
Specifications are subject to change without notice.
Mass and dimensions are approximate.
•
Total harmonic distortion is measured by the digital
spectrum analyser.
Power supply
Power consumption
AC 220 V to 240 V, 50/60 Hz
225 W
Power consumption in standby mode (approximate)
With “BLUETOOTH STANDBY” set to “OFF”
0.5 W
With “BLUETOOTH STANDBY” set to “ON”
0.6 W
AKX710 GS TQBJ2138.book Page 20 Thursday, July 12, 2018 10:50 AM
offset printing
