– 3



Mount the nozzle on the spray pipe
(markings on the adjustment ring at the
top).



Connect ray tube to hand spray gun



Draw the push-handle upwards until the
stop.



Fix the push-handle using the enclosed
screws and tool.



Fasten the high pressure hose to the
high pressure connection.



Insert the crank in the hose drum shaft
and lock it in.



Before rolling up, stretch out the high
pressure hose.



Wind the high pressure hose in uniform
layers on the hose drum by rotating the
crank.  Select the rotation direction in
such a way that the high pressure hose
does not get bent.



Danger

Danger of injury by electric shock.
The appliance may only be connected to al-
ternating current.
The appliance may only be connected to an
electrical supply which has been installed in
accordance with IEC 60364.
The voltage indicated on the type plate
must correspond to the voltage of the elec-
trical source.
The minimum fuse rating required at the

socket outlet is (see technical specifica-

tions).

The highest allowed net impedance at the

electrical connection point (refer to techni-

cal data) is not to be exceeded. In case of

confusion regarding the power impedance

present on your connection, please contact

your utilities provider.

The appliance should always be connected

to the electrical mains using a plug. It is for-

bidden to permanently connect the appli-

ance to the power supply. The plug is only

for mains separation.

Check the power cord with mains plug for

damage before every use. If the power cord

is damaged, please arrange immediately

for the exchange by an authorized custom-

er service or a skilled electrician.

The plug and coupling of the extension ca-

ble used must be watertight.

Use the extension cord that has an ade-

quate cross-section (see "Technical Data")

and unwind it fully from the cable drum.

Unsuitable extension cables can be haz-

ardous. Only use extension cables out-

doors which have been approved for this

purpose and labelled with a sufficient cable

cross section:

For connection values, see type plate/tech-
nical data.

몇

Warning

Observe regulations of water supplier.
According to the applicable regula-

tions, the appliance must never be

used on the drinking water supply

without a system separator. Use a

suitable system separator manufactured by

KÄRCHER; or, as an alternative, a system sep-

arator as per EN 12729 Type BA. Water flowing

through a system separator is considered non-

drinkable.

Caution

Always connect the system separator to
the water supply, never directly to the appli-
ance!

For connection values refer to technical
specifications



Connect the supply hose (minimum
length 7.5 m, minimum diameter 3/4“) to
the water connection point of the ma-
chine and at the water supply point (for
e.g. a tap).

Note

The supply hose is not included.



Open the water supply.

Attaching the Accessories

In devices without hose drum:

In devices without hose drum:

Start up

Electrical connection

Water connection

Connection to the water supply

17

EN
