English

We hereby declare that the machine described below
complies with the relevant basic safety and health re-
quirements of the EU Directives, both in its basic design
and construction as well as in the version put into circu-
lation by us. This declaration shall cease to be valid if
the machine is modified without our prior approval.

The signatories act on behalf of and with the authority of
the company management.

Documentation supervisor:
S. Reiser

Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Straße 28-40
71364 Winnenden (Germany)
Tel.: +49 7195 14-0
Fax: +49 7195 14-2212

Winnenden, 2018/10/01

Technical specifications

Electrical connection

Voltage

220-240
1~50-60

V
Hz

Connected load

2,1 kW

Protection class

IP X5

Protective class

II

Mains fuse (slow-blow)

10 A

Water connection

Max. feed pressure

1,2 MPa

Max. feed temperature

40 °C

Min. feed volume

9 l/min

Max. Suction height

0,5 m

Performance data

Working pressure

12 MPa

Max. permissible pressure

14,5 MPa

Water flow rate

6,7 l/min

Max. flow rate

8,3 l/min

Detergent flow rate

0,3 l/min

Recoil force of trigger gun

17 N

Dimensions and weights

Length

310 mm

Width

336 mm

Height

860 mm

Weight, ready to operate with
accessories

9,5 kg

Values determined as per EN 60335-2-79

Hand-arm vibration value
Uncertainty K

<2,5

0,6

m/s

2

m/s

2

Sound pressure level L

pA

Uncertainty K

pA

79

3

dB(A)
dB(A)

Sound power level L

WA

 + Uncertainty

K

WA

95 dB(A)

Subject to technical changes.

EU Declaration of Conformity

Product:

High pressure cleaner

Type:

1.950-xxx

Relevant EU Directives

2006/42/EC (+2009/127/EC)
2014/30/EU
2011/65/EU
2000/14/EC

Applied harmonized standards

EN 50581
EN 55014–1:2017
EN 55014–2: 2015
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2014
EN 61000–3–3: 2013
EN 62233: 2008

Applied conformity evaluation method

2000/14/EC: Appendix V

Sound power level dB(A)

Measured:

92

Guaranteed:

95

Chairman of the Board of Management

Director Regulatory Affairs & Certification
