English

 21

See fold-out page 4 for illustrations



Illustrations

 -

Mount loose parts delivered with appliance prior to
start-up.



Fasten the quick coupling for the high pressure
hose to the high pressure connection.



Illustration
Push the high pressure hose into the trigger gun
until it locks audibly.

Note:

 Make sure the connection nipple is aligned

correctly.



Check the secure connection by pulling on the high
pressure hose.



Park the appliance on an even surface.



Push the high pressure hose into the quick cou-
pling until it locks audibly.

Note:

 Make sure the connection nipple is aligned

correctly.
Check the secure connection by pulling on the high
pressure hose.



Insert the mains plug into the socket.

For connection values, see type plate/technical data.

ATTENTION

Impurities in the water can damage the high-pressure
pump and the accessories. For protection, the use of
the KÄRCHER water filter (optional accessory, order
no. 4.730-059) is recommended.

Observe regulations of water supplier.



Attach the water supply hose to the coupling on the
water connection.



Connect the water supply hose to the water supply.



Completely open the water tap.

Note:

 The max. suction height is 0.5 m.

This high-pressure cleaner is suited to work with the
KÄRCHER suction hose with backflow valve (Optional
accessory, order no. 4.440-238) to draw in surface wa-
ter, e.g. from water butts or ponds (see specifications for
max. suction height).



Remove coupling from the water connection.



Fill the suction hose with water.



Screw the suction hose into the water connection of
the appliance and insert it into the water source
(e.g. rainwater drum).

Remove air from appliance before operation.



Turn on the appliance “I/ON”.



Unlock the lever on the trigger gun.



Pull on the lever of the trigger gun; the device will
switch on.



Let the appliance work until the water exits at the
hand spray gun without bubbles (max. 2 minutes).



Release the lever on the trigger gun.

Note:

 Release the lever of the trigger gun; the de-

vice will switch off again. High pressure remains in
the system.



Lock the lever on the trigger gun.

Assembly

Start up

Water supply

Water supply from mains

Drawing in water from open reservoirs
