– 6

The scope of delivery of your appliance is il-
lustrated on the packaging. Check the con-
tents of the appliance for completeness
when unpacking.
In the event of missing accessories or any
transport damage, please contact your
dealer.

Illustrations on Page 2

1 Coupling element for water connection
2 High pressure hose
3 Quick coupling for high pressure hose
4 Water connection with integrated sieve

5 Appliance switch "0/OFF“/ „I/ON“

6 Transport handle

7 Suction hose for detergent

8 Storage for accessories

9 Mains cable with mains plug

10 Wheels

11 Trigger gun

12 Lock trigger gun

13 Key to detach the high pressure hose

from the trigger gun

14 Spray lance with Dirtblaster

15 Spray lance with pressure regulation

(Vario Power)

Special accessories expand the possibilities
of using your appliance. Please contact your
KÄRCHER dealer for further information.

Mount loose parts delivered with appliance
prior to start-up.



Illustration
Push the wheels into the intake and se-
cure with the enclosed plugs, watch for
positioning of plug.



Illustration
Place the transport handle into the in-
take until you feel resistance. Use the
heel of your hand or a soft rubber mallet
to position it.



Illustration
Hook the accessories net into the hooks
shown in the illustration.



Illustration
Push the high pressure hose into the
trigger gun until it locks audibly.

Note:

 Make sure the connection nipple

is aligned correctly.
Check the secure connection by pulling
on the high pressure hose.

몇

Warning

According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.

Caution

Always connect the system separator to
the water supply, never directly to the appli-
ance!

Note:

 Impurities in the water can damage

the high-pressure pump and accessories.
For protection, the use of the KÄRCHER
water filter (optional accessory, order no.
4.730-059) is recommended.

Observe regulations of water supplier.
For connection values, see type plate/tech-
nical data.



Use a fibre-reinforced water hose (not
included) with a standard coupling.
(Minimum diameter 1/2 inch (13 mm),
minimum length 7.5 m).



Illustration
Screw the coupling element to the wa-
ter connection on the appliance.
Push the water supply hose onto the
coupling unit, then connect it to the wa-
ter supply.

Operation

Scope of delivery

Description of the Appliance

Special accessories

Before Startup

Install wheels

Install the transport handle

Attach the accessories net

Connect the high pressure hose to the
hand spray gun

Water supply

Water supply from mains
