4
Î
Connect ray tube with hand spray gun
Î
Insert high pressure nozzle into covering
nut
Î
Install covering nut and tighten firmly
Î
Connect the high pressure host to the high
pressure connection point of the machine.
Figure 4
Figure 5
For connection values refer to technical specifi-
cations
Î
Connect the supply hose (minimum length
7.5 m, minimum diameter 3/4“) to the water
connection point of the machine and at the
water supply point (for e.g. a tap).
Note:
The supply hose is not included.
If you want to suck in water from an exter-
nal vessel, the following modification is
necessary:
Î
Remove water connection from the pump
head.
Î
Unscrew the upper supply hose with the
fine filter to the swimmer container and con-
nect it to the pump head.
Î
Connect suction hose (minimum diameter
3/4“) with filter (accessory) to the water con-
nection point.
–
Max. suck height: 0.5 m
Until the pump sucked in water, you should:
Î
Turn the pressure and quantity regulation to
MAX.
Î
Close the dosing valve for the detergent.
Danger
Never suck in water from a drinking water
container. Never suck in liquids which con-
tain solvents like lacquer thinner, petrol, oil
or unfiltered water. The sealings within the
device are not solvent resistant. The spray
mist of solvents is highly inflammable, ex-
plosive and poisonous.
–
For connection values, see technical
data and type plate.
–
The electrical connections must be
done by an electrician according to IEC
60364-1.
Danger
Danger of injury by electric shock.
–
Unsuitable extension cables can be
hazardous. Only use extension cables
outdoors which have been approved for
this purpose and labelled with a suffi-
cient cable cross section:
–
Always unwind extension lines com-
pletely.
–
The plug and coupling of the extension
cable used must be watertight.
Caution
The maximum tolerable mains impedance
at the electrical contact point (see Techni-
cal Data) must not be exceeded.
Caution
Check direction of rotation of the engine at
every socket change.
–
With correct direction of rotation a
strong airflow can be felt out of the ex-
haust opening of the burner.
Figure 14
Î
Exchange the poles at the device plug if
the rotation direction is wrong .
Danger
Risk of explosion!
Do not spray flammable liquids.
Caution
Never operate device with empty fuel tank
The fuel pump will otherwise be destroyed.
Install hand spray gun
Installing spare high pressure hose
Installing the handle
Water connection
suck in water from vessel
Power connection
Operation
20
EN
