15

Other interruptions can only be removed by
the Service.

order number: 2.639-743

order number: 2.640-942

order number: 2.639-753

order number: 3.640-262

order number: 2.641-120

German, order number: 5.391-180
English, order number: 5.391-181
French, order number: 5.391-182
Italian, order number: 5.391-183
Spanish, order number: 5.391-184
Portuguese, order number: 5.391-185
Dutch, order number: 5.391-186
Greek, order number: 5.391-187
Swedish order number: 5.391-189
Finnish, order number: 5.391-190
Norwegian, order number: 5.391-191
Danish, order number: 5.391-192
Estnish, order number: 5.391-193
Lithuanien, order number: 5.391-194
Lettish, order number: 5.391-195
Russian, order number: 5.391-196
Polish, order number: 5.391-197
Hungarian, order number: 5.391-198
Czech, order number: 5.391-199
Slowakian, order number: 5.391-200
Romanian, order number: 5.391-202
Croatian order number: 5.391-203

order number: 6.414-278

order number: 6.393-474
Without content.

order number: 6.393-209
Without content.

order number: 6.393-480
Without content.
Lid for the cleaning agent container 10 liter,
order number: 6.393-045

order number: 6.288-020

Order no. : 6.288-072.0

Order no. : 6.288-116.0

Order no. : 6.290-911.0

order number: 6.287-016
25 kg, for option base exchanger

For the optional softener:

몇

Warning!

Before using the cleaning agent, please re-
fer to the notice on the package. Do not use
the following cleaning agents:

–

cleaning agent containing nitrit acid

–

cleaning agent containing active chlo-
rinate

If you use such cleaning agents, it will dam-
age your equipment.

The cleaning agents are to be used undiluted.

RM 100 ASF
RM 101 ASF

The warranty terms published by our com-
petent sales company are applicable in
each country. We will repair potential fail-
ures of your accessory within the warranty
period free of charge, provided that such
failure is caused by faulty material or de-
fects in fabrication. In the event of a warran-
ty claim please contact your dealer or the
nearest authorized Customer Service cent-
er. Please submit the proof of purchase.

–

Only use accessories and spare parts
which have been approved by the man-
ufacturer. The exclusive use of original
accessories and original spare parts
ensures that the appliance can be oper-
ated safely and trouble free.

–

For additional information about spare
parts, please go to the Service section
at www.kaercher.com.

Caution

Risk of injury and damage! Observe the
weight of the appliance when you transport it.

Caution

Risk of injury and damage! Note the weight
of the appliance in case of storage.

Notice

The equipment may only be installed by an

–

mechanic of Kärcher

–

or an from Kärcher authorized individual

The following requirements are necessary
in order to install the equipment:
The plant may be used for diverting com-
bustible gases only in the open.
If the plant is to be housed under a roof or in
a closed room, then it must be connected to
a chimney to provide an outlet for the exhaust
gases.  If the plant is to be connected to a
chimney, then the burner needs to be adjust-
ed and the exhaust values must be checked
by the concerned chimney cleaner.

–

Straigh even area, with a solid subsoil
with the measures of 1040x725 mm.

–

For the option of the base exchanger/Os-
mose an additional area of 845 x 725 mm.

–

Using the option of the base exchanger/
Osmose: Water connection with pipe
separator according to DIN 1717, per-
forming data, refer to " technical data".
Please pay attention to the national re-
quirements  (in Germany DVGW).

–

Power connection, refer to "technical
data".

–

By customer, lockable, access for the
wash customer emergency - off- main
switch.

Interruptions at the base exchanger (optional)

Interruption

Possible cause

Repair

By whom

base exchanger
does not regenerate

No power supply

Check power supply (fuse, switch, jack).

Operator, Main-
tenance

Switch clock at the head of the base exchanger
is wrong adjusted or, after an interruption of the
power supply was not adjusted.

Set the time at the switch clock.

Operator

The water stays
hard after the regen-
erartion

No salt in the salt tank

Fill in salt, let the level of the salt not get below the water level. Operator

No sole suction

water input pressure is too low

Increase the water pressure to the minimum of 0,2 MPa (2 bar)
.

Operator

Accessories

Attachment sets

Additional feature swinging arm comfort

Additional feature swinging arm

Additional feature thermostat

Additional feature half load valve

Additional feature anti theft device

Sticker operation instruction

Water filter G 1“

container

Cleaning agent container 25 liter

Fuel container 40 liter

Cleaning agent container 10 liter

Fuel

Motor oil Hypoid SAE 90

Silicon grease

Lock grease

Steel care product

Water softening salt in form of tabletts

Softener RM 110

Detergent

CHEM 1

RM 806 ASF

CHEM 2

RM 820

CHEM 3

RM 825 ASF

Lime solvent

Warranty

Spare parts

Transport

Storage

Installing the unit

(only for experts)

Preparing the installation place

38

EN
