Continuous Lighting of the Green Battery Charge
Indicator

Full

Continuous lighting

 of the battery charge in-

dicator indicates that the battery is fully

charged.
When the battery is not inserted,

continuous lighting

 of the

battery charge indicator indicates that the mains plug is in-
serted in the socket outlet and that the battery charger is
ready for operation.

Continuous Lighting of the Red Battery Charge Indicator

Continuous lighting

 of the

red

 battery charge

indicator indicates that the temperature of the

battery is not within the allowable charging temperature
range, see section “Technical Data”. As soon as the allowable
charging temperature range is reached, the battery charger
automatically switches to rapid charging.

Flashing Red Battery Charge Indicator

A

flashing red

 battery charge indicator indic-

ates a different malfunction of the charging

procedure, see section “Troubleshooting – Causes and Cor-
rective Measures”.

Operation

Starting

Always use fresh water to fill the water tank. Check if the fil-
ter

(10)

 is inserted and undamaged (see figure

C

).

Connect the hose

(4)

 to the water outlet

(9)

 and the spray

gun

(18)

 (see figure

F

).

Select the desired spray pattern by rotating the nozzle head

(1)

 (see figure

I

).

Select the desired jet strength with the pressure selector

(12)

 (see figure

H

).

Press the On/Off switch

(13)

 and pull and hold the trigger

(2)

 until water comes out (see figure

G

).

Note

: It can take up to 10 seconds for water to come out

when the product is first used after the water tank has been
emptied.

Autostop Function

The machine is designed to switch off the motor as soon as
the spray-gun trigger

(2)

 is released.

Dry-running Protection

The motor shuts off when the pump runs without water for
more than

20

 seconds.

Switch off the machine and refill the water tank. Then,
switch the machine on again.

Sleep Function

The machine automatically switches off after

5

 minutes

without operation.

Mounting/dismounting the brush (see figure J)

The brush

(5)

 mounts onto the spray gun and makes clean-

ing more effective.
Slide the brush straight onto the spray gun

(18)

. Guide the

upper and bottom clip of the brush into the corresponding
openings on the spray gun.
Remove the brush by pressing the bottom clip upward and
pulling the brush off the spray gun.

Troubleshooting

Cordless pressure cleaner

Problem

Possible Cause

Corrective Action

Motor refuses to start

Battery discharged

Recharge battery

Battery too hot/cold

Allow to cool/warm

Machine frozen

Wait until machine has defrosted

Pressure pulsating

Blocked nozzle

Clean nozzle

Air in pump

Operate machine in turbo-pressure mode with
nozzle set to shower jet until system is air-free

Motor running but no
or limited working
pressure

Water tank empty

Refill water tank

Pump not vented

Press and hold trigger to vent air

Power indication lights
up but pump no longer
running

Dry-running protection has been activated

Switch machine off, refill water tank and switch
machine on again

Machine switches off

Sleep function has been activated

Press On/Off switch for activation

Battery discharged

Recharge battery

Water leaks from ma-
chine

Leaking pump

Slight water leaks are possible; in case of excess-
ive leaks, contact Bosch Service Centre
