Technical

information

Preparation

z

  Take out the required length of cable from the cable tidy on the base of the device and connect the device

to the mains supply.

z

  All parts of the stand mixer are to be thoroughly cleaned before being used for the first time.

Assembly

Instructions

1

1.Mount the jar sealing ring onto the blade base ,and Mount the blade base into the jar base, and the inside ring
of jar base is tighten on jar base as far as fixed the blade base tightly.
2.After putting the ingredients in the jar, fix the lid onto the jar by pressing down.
3.Insert the Measuring cup into the opening of the lid, and tune it in anticlockwise direction until it is locked.
4.Mount the jar with jar unit onto the main base, and tune the jar in anticlockwise direction until the jar is locked.

Assembly

Instructions

2

1.To open the upper housing cover (4), using the small knob (7). Fig.2 Fig.3

2. To attach the mixing bowl, ensure the control speed on OFF. Place the mixing bowl (11) on the device plate,
and turn the mixing bowl unit in

anticlockwise direction until it is fixed. Fig.4

3. To attach the dough blade (12) or the eggs whisk (10) or the mixer blade (13) on the blade connector, rotate
the blade shaft clockwise until it engages firmly. Fig.5

4. To lock the motor head, make sure the head is completely down. Ensure the small knob is on LOCK position
by turn it in the direction of the arrow (on the machine). Fig.6   Fig.7
5. To operate speed control, it should always be set lowest speed for starting, then move to the desired speed
for work. Position “P” is used for short time high speed usage.

MODELLO

SMX5

SEM7

SL-B5

SL-B7

Voltage

220-240V 220-240V

220-240V 220-240V

Frequency

50-60Hz 50-60Hz

50-60Hz 50-60Hz

Agitator kettle capacity

5,5 7

5,5 7

Glass jar capacity

1,5 1,5

1,5 1,5
