4
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven and may split or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton.
Your oven comes with the following accessories:
Glass tray
1
Turntable ring assembly
1
Instruction Manual
1
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
H) Grill rack
Shuts off oven power if door is opened during operation.
TURNTABLE INSTALLATION
Hub (underside)
Glass tray
Turntable shaft
Turntable ring assembly
a. Never place the glass tray upside down. The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly must always be used during cooking.
c. All food and containers of food should be always placed on the glass tray for cooking.
d. The glass tray rotates clockwise; this is normal.
e. If glass tray or turntable ring assembly cracks or breaks, contact your nearest authorized service centre.
Installation
Remove all packing material and accessories.
Examine the oven for any damage such as dents or broken door. Do not install if oven is damaged.
Countertop
Cabinet: Remove any protective film found on the cabinet surface.
Do not remove the light brown Mica cover that is screwed to the oven cavity to protect the magnetron.
Installation
1. Select a level surface that provide enough open space for the intake and/or outlet vents. A minimum clearance of 3.0
inch (7.5cm) is required between the oven and any adjacent wall. One side must be open.
(1) Leave a minimum clearance of 12 inch(30cm) above the oven.
(2) Do not remove the legs from the bottom of the oven.
(3) Blocking the intake and/or outlet openings can damage the oven.
(4) Place the oven as far away from radios and TV as possible. Operation of microwave oven may cause interference to
your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency is the same as the voltage
and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance. If installed could be damaged
and the warranty would be void.
The accessible surface may be hot during operation.
OPERATION
1. Operation and Function
1. Clock Setting
Plug in the oven, "0:00" will be shown and a "beep" will be heard.
ENGLISH
Vt-1665-new.qxd 20.10.04 15:38 Page 4
