Overview of Components

UEFI BIOS

UEFI BIOS

MSI UEFI BIOS is compatible with UEFI (Unified Extensible Firmware Interface)

architecture. UEFI has many new functions and advantages that traditional BIOS

cannot achieve, and it will completely replace BIOS in the future. The MSI UEFI

BIOS uses UEFI as the default boot mode to take full advantage of the new chipset’s

capabilities. However, it still has a CSM (Compatibility Support Module) mode to be

compatible with older devices. That allows you to replace legacy devices with UEFI

compatible devices during the transition.

⚠

Important

The term BIOS in this user guide refers to UEFI BIOS unless otherwise noted.

UEFI advantages

∙

Fast booting - UEFI can directly boot the operating system and save the BIOS self-

test process. And also eliminates the time to switch to CSM mode during POST.

∙

Supports for hard drive partitions larger than 2 TB.

∙

Supports more than 4 primary partitions with a GUID Partition Table (GPT).

∙

Supports unlimited number of partitions.

∙

Supports full capabilities of new devices - new devices may not provide backward

compatibility.

∙

Supports secure startup - UEFI can check the validity of the operating system to

ensure that no malware tampers with the startup process.

Incompatible UEFI cases

∙

32-bit Windows operating system

- this motherboard supports only 64-bit

Windows 10 operating system.

∙

Older graphics card

 - the system will detect your graphics card. When display a

warning message

There is no GOP (Graphics Output protocol) support detected in

this graphics card.

⚠

Important

We recommend that you to use a GOP/ UEFI compatible graphics card.

How to check the BIOS mode?

After entering the BIOS, find the BIOS Mode at the top of the screen.

UEFI boot mode

CSM boot mode

CPU Temperature:

Motherboard Temperature:

VCore:

DDR Voltage:

BIOS Mode:

UEFI

/CSM

CPU Temperature:

Motherboard Temperature:

VCore:

DDR Voltage:

BIOS Mode: UEFI/

CSM
