- 45 -
BIOS Setup
2-6 Integrated Peripherals
eXtreme Hard Drive (Intel P67
j
/H67
kl
Chipset)
Enables or disables the X.H.D function for the SATA controllers integrated in the Intel P67
j
/H67
kl
Chipset. When set to
Enabled
, the
PCH SATA Control Mode
item below will be set to
RAID(XHD)
automatically. For details on using the GIGABYTE X.H.D utility, refer to Chaper 4, "eXtreme Hard Drive
(X.H.D)." (Default: Disabled)
PCH SATA Control Mode (Intel P67
j
/H67
kl
Chipset)
Enables or disables RAID for the SATA controllers integrated in the Intel P67
j
/H67
kl
Chipset or con-
figures the SATA controllers to AHCI mode.
IDE
Disables RAID for the SATA controllers and configures the SATA controllers to IDE
mode. (Default)
RAID(XHD)
Enables RAID for the SATA controllers.
AHCI
Configures the SATA controllers to AHCI mode. Advanced Host Controller Interface
(AHCI) is an interface specification that allows the storage driver to enable advanced
Serial ATA features such as Native Command Queuing and hot plug.
SATA Port0-3 Native Mode (Intel P67
j
/H67
kl
Chipset)
Specifies the operating mode of the integrated SATA controllers.
Disabled
Allows the SATA controllers to operate in Legacy IDE mode.
In Legacy mode the SATA controllers use dedicated IRQs that cannot be shared with
other device. Set this option to
Disabled
if you wish to install operating systems that
do not support Native mode.
Enabled
Allows the SATA controllers to operate in Native IDE mode.
Enable Native IDE mode if you wish to install operating systems that support Native
mode. (Default)
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD)
[Disabled]
PCH SATA Control Mode
[IDE]
SATA Port0-3 Native Mode
[Enabled]
USB Controllers
[Enabled]
USB Legacy Function
[Enabled]
USB Storage Function
[Enabled]
Azalia Codec
[Auto]
Onboard H/W LAN
[Enabled]
SMART LAN
[Press Enter]
Onboard LAN Boot ROM
[Disabled]
Onboard USB 3.0 Controller
jk
[Enabled]
USB3.0 Turbo
jk
[Disabled]
Onboard Serial Port 1
[3F8/IRQ4]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
j
Only for GA-P67A-UD3
k
Only for GA-PH67A-UD3
l
Only for GA-PH67-UD3
