- 95 -
Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
5-1-2 Configuring Marvell 88SE9128 SATA Controllers
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to avail-
able SATA port on the motherboard. One of the Marvell 88SE9128 SATA controllers controls the onboard
GSATA3_6/7 connector and the other controls the eSATA ports on the back panel. Then connect the power
connector from your power supply to the hard drive.
B. Configuring SATA controller and RAID mode in BIOS Setup
Make sure to configure the SATA controller mode correctly in system BIOS Setup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to
Inte-
grated Peripherals
. To enable RAID, see the table below for configuring different SATA controllers for RAID.
Set
GSATA3 Ctrl Mode/eSATA3 Ctrl Mode
to
IDE
or
AHCI
, depending on your requirements (Figure 1). (In
AHCI mode, installation of the SATA AHCI driver is required during Windows XP installation.) Refer to section,
"5-1-3," for more details.
Figure 1
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
Integrated Peripherals
SMART LAN1
[Press Enter]
SMART LAN2
[Press Enter]
Onboard LAN1 Boot ROM
[Disabled]
Onboard LAN2 Boot ROM
[Disabled
Onboard USB 3.0 Controller
[Enabled]
USB3.0 Turbo
[Disabled]
Onboard USB 3.0 Controller2
[Enabled]
GSATA3 Controller
[Enabled]
GSATA3 Ctrl Mode
[IDE]
GSATA3 Transaction Mode
[Fw Mode]
GSATA3 RAID Configuration
[Press Enter]
eSATA3 Controller
[Enabled]
eSATA3 Ctrl Mode
[IDE]
eSATA3 Transaction Mode
[Fw Mode]
eSATA3 RAID Configuration
[Press Enter]
SATA3 Firmware Selection
[Auto]
higf
: Move
Enter: Select
+/-/PU/PD: Value
F10: Save
ESC: Exit
F1: General Help
F5: Previous Values
F6: Fail-Safe Defaults
F7: Optimized Defaults
Item Help
Menu Level
Controller Connectors
BIOS Settings
Marvell
GSATA3_6/7
Set
GSATA3 Controller
to
Enabled
88SE9128
Set
GSATA3 Ctrl Mode
to
IDE
or
AHCI
Marvell
eSATA
Set
eSATA3 Controller
to
Enabled
88SE9128
Set
eSATA3 Ctrl Mode
to
IDE
or
AHCI
Step 2:
Then make sure
GSATA3 Transaction Mode
/
eSATA3 Transaction
Mode
is set to
Fw Mode
. To create a
RAID array, press <Enter> on the
GSATA3 RAID Configuration/eSATA3 RAID Configuration
item to enter
the RAID configuration menu. Skip this step if you do not want to create RAID.
