- 41 -
BIOS Setup
>>>>> Standard Clock Control
Base Clock(BCLK) Control
Enables or disables the control of CPU base clock.
Enabled
will allow the
BCLK Frequency(Mhz)
item
below to be configurable. Note: If your system fails to boot after overclocking, please wait for 20 seconds
to allow for automated system reboot, or clear the CMOS values to reset the board to default values.
(Default: Disabled)
BCLK Frequency(Mhz)
Allows you to manually set the CPU base clock. The adjustable range is from 100 MHz to 1200 MHz.
This item is configurable only if the
Base Clock(BCLK) Control
option is enabled.
Important:
It is highly recommended that the CPU frequency be set in accordance with the CPU specifi-
cations.
PCI Express Frequency(Mhz)
Allows you to manually set the PCIe clock frequency. The adjustable range is from 90 MHz to 150 MHz.
Auto
sets the PCIe clock frequency to standard 100 MHz. (Default: Auto)
C.I.A.2
CPU Intelligent Accelerator 2 (C.I.A.2) is designed to automatically adjust CPU computing power to
maximize system performance. C.I.A.2 allows your system bus to be changed dynamically based on
CPU loading through the use of 5 preset states.
Note: System stability varies, depending on your system hardware components.
Disabled
Disables the use of C.I.A.2. (Default)
Cruise
Increases CPU frequency by 5% or 7% depending on CPU loading.
Sports
Increases CPU frequency by 7% or 9% depending on CPU loading.
Racing
Increases CPU frequency by 9% or 11% depending on CPU loading.
Turbo
Increases CPU frequency by 15% or 17% depending on CPU loading.
Full Thrust
Increases CPU frequency by 17% or 19% depending on CPU loading.
Warning:
Before using C.I.A.2, please first verify the overclocking capability of your CPU. As stability is
highly dependent on system components, when system instability occurs after overclocking, lower the
overclocking ratio.
>>>>> Advanced Clock Control
CPU Clock Drive
Allows you to adjust the amplitude of the CPU and North Bridge clock.
Options are: 700mV, 800mV (default), 900mV, 1000mV.
PCI Express Clock Drive
Allows you to adjust the amplitude of the PCI Express and North Bridge clock.
Options are: 700mV, 800mV, 900mV (default), 1000mV.
CPU Clock Skew
Allows you to set the CPU clock prior to the North Bridge clock.
Options are: 0ps~750ps. (Default: 0ps)
IOH Clock Skew
Allows you to set the North Bridge clock prior to the CPU clock.
Options are: 0ps~750ps. (Default: 0ps)
