GA-945GCM-S2 (rev. 2.1) Motherboard
- 38 -
English
2 . If no cable problem is detected on the LAN cable connected to a 10/100 Mbps hub, the
Status
fields of Pair 1 -2 and Pair 3-6 will show
Normal
and the
Length
fields will show
N/A
.
However, because Pair 4-5 and Pair 7-8 are not used in a 10/100 Mbps environment, their
Status
fields will show
Short
or
Open
, and the length shown is the approximate length of the
attached LAN cable.
When a Cable Problem Occurs...
If a cable problem occurs on a specified pair of wires, the
Status
field will show
Short
or
Open
and the length shown will be the approximate distance to the fault or short.
For example, if it shows
P a i r 1 - 2 S t a t u s = S h o r t / L e n g t h = 1 . 6 m
,
it means that a fault or short might occur at about 1.6m on Pair 1-2.
When No LAN Cable Is Attached...
If no LAN cable is attached to the motherboard, the
Status
fields of all four pairs of wires will show
Open
and the
Length
fields show
0.0m
.
Onboard LAN Boot ROM
This function decide whether to invoke the boot ROM of the onboard LAN chip.
Enabled
Enable this function.
Disabled
Disable this function. (Default value)
Onboard Serial Port 1
Auto
BIOS will automatically setup the port 1 address.
3F8/IRQ4
Enable onboard Serial port 1 and address is 3F8/IRQ4. (Default value)
2F8/IRQ3
Enable onboard Serial port 1 and address is 2F8/IRQ3.
3E8/IRQ4
Enable onboard Serial port 1 and address is 3E8/IRQ4.
2E8/IRQ3
Enable onboard Serial port 1 and address is 2E8/IRQ3.
Disabled
Disable onboard Serial port 1.
Onboard Serial Port 2
Auto
BIOS will automatically setup the port 2 address.
3F8/IRQ4
Enable onboard Serial port 2 and address is 3F8/IRQ4.
2F8/IRQ3
Enable onboard Serial port 2 and address is 2F8/IRQ3. (Default value)
3E8/IRQ4
Enable onboard Serial port 2 and address is 3E8/IRQ4.
2E8/IRQ3
Enable onboard Serial port 2 and address is 2E8/IRQ3.
Disabled
Disable onboard Serial port 2.
Onboard Parallel Port
Disabled
Disable onboard LPT port.
378/IRQ7
Enable onboard LPT port and address is 378/IRQ7. (Default value)
278/IRQ5
Enable onboard LPT port and address is 278/IRQ5.
3BC/IRQ7
Enable onboard LPT port and address is 3BC/IRQ7.
