ENGLISH

51

More about this unit

  General

Turning on the power

•  By pressing SOURCE on the unit, you can

also turn on the power. If the source is ready,
playback starts.

Watching picture

•  If you change the aspect ratio to “Just,” both

sides of the picture are extended horizontally
to fit the picture to the monitor size. It may
cause the center portion of the picture to look
distorted.

  FM/AM

Storing stations in memory

•  When SSM is over, received stations are

preset in No. 1 (lowest frequency) to No. 6
(highest frequency).

  Disc

General

•  In this manual, words “track” and “file” are

interchangeably used.

•  This unit can also play back 8 cm discs.
•  This unit can only play back audio CD

(CD-DA) files if different type of files are
recorded in the same disc.

•  This unit can display only one-byte

characters. No other characters can be
correctly displayed.

Inserting a disc

•  When a disc is inserted upside down, “Disc

Error Please Eject” appears on the monitor.
Eject the disc.

Ejecting a disc

•  If the ejected disc is not removed within

15 seconds, the disc is automatically inserted
again into the loading slot to protect it from
dust. (Disc will not play this time.)

Speaker/signal indicators

•  Normally, Standby Reception indicators light

up instead of the speaker/signal indicators.

•  The speaker indicators—squares around “L,”

“R,” “LS,” and “RS” lights in light blue, when
the corresponding speakers are set to “Large”
or “Small” (

☞

 page 45).

•  The center speaker indicator—square around

“C” lights in light blue, when the center
speaker is set to “Large” or “Small” and when
surround is activated.

•  Sounds come out of the speakers whose

speaker indicators are lit on the monitor.

•  The SW indicator lights up when “Sub

Woofer” is set to “On” (

☞

 page 45).

•  The signal indicators indicate the incoming

signals—L (front left) / R (front right) / C
(center) / LFE (low frequency effect) / LS (left
surround) / RS (right surround) / S (monaural
surround).

•  If the speaker is activated, but the signals

corresponding to the speaker are not coming
in, the signal indicators changes their color
from white to black to indicate no signals
coming in (therefore no sound comes through
the corresponding speakers).

Changing the source

•  If you change the source with Dual Zone

deactivated, playback also stops without
ejecting the disc.

  Next time you select “DISC” for the playback

source, disc play starts from where it has been
stopped previously.

Speaker indicators

Signal indicators
