16

ENGLISH

Indication, [Range]

BASS

*

2

, [–06 to +06]

Adjust the bass.

MIDDLE

*

2

 (mid-range), [–06 to +06]

Adjust the mid-range frequencies sound level.

TREBLE

*

2

, [–06 to +06]

Adjust the treble.

FADER

*

3

, [R06 to F06]

Adjust the front and rear speaker output balance.

BALANCE

*

4

, [L06 to R06]

Adjust the left and right speaker output balance.

LOUD

*

5

 (loudness), [LOUD ON or LOUD OFF]

Boost low and high frequencies to produce a
well-balanced sound at a low volume level.

SUB.W

*

1

, [00 to 08, initial: 04]

Adjust the subwoofer output level.

VOL ADJ

 (volume adjust), [–05 to +05, initial: 00]

Adjust the volume level of each source (except FM), in
relation to the FM volume level. The volume level will
automatically increase or decrease when you change
the source.
•  Before making an adjustment, select the source you

want to adjust.

VOLUME

, [00 to 50 or 00 to 30]

*

6

Adjust the volume.

*

1

  Displayed only when “L/O MODE” is set to “SUB.W”

(see page 18).

*

2

  When you adjust the bass, mid-range, treble, or

loudness, the adjustment you have made is stored
for the currently selected sound mode (iEQ) including
“USER.”

*

3

  If you are using a two-speaker system, set the fader

level to “00.”

*

4

  This adjustment will not affect the subwoofer output.

*

5

  The adjustment made (LOUD ON/LOUD OFF) will be

applied to all sound modes.

*

6

  Depending on the amplifier gain control setting. (See

page 19  for details.)

Sound adjustments

You can select a preset sound mode suitable to the
music genre (iEQ: intelligent equalizer).

1

2

Indication (For)

BASS

MIDDLE

TREBLE

LOUD

USER

(Flat sound)

00

00

00

OFF

ROCK

(Rock or disco music)

+03

00

+02

OFF

CLASSIC

(Classical music)

+01

00

+03

OFF

POPS

(Light music)

+02

+01 +02

OFF

HIP HOP

(Funk or rap music)

+04

–02

+01

OFF

JAZZ

(Jazz music)

+03

00

+03

OFF

Adjusting the sound

You can adjust the sound characteristics to your
preference.

1

2

Preset values
