TFT auto open:

 set the monitor working mode when the unit  is on and off: On (when the unit  is off the monitor

draws down into the unit automatically, when it s on the monitor unfurls automatically), Off (when the unit is off
the monitor draws down into the unit automatically, when it s on the monitor unfurls by pressing the
OPEN/CLOSE button on the panel), Manual (when the unit  is off or on the monitor draws down or unfurls only
by pressing the OPEN/CLOSE button on the panel).

Audio sound processing configuration

1.  Enter the ASP CONFIG menu.
2.  Use the

 buttons on the panel or

8

/   buttons on the RC or touch

the desired item on the screen to select the desired setting: Bass center
freq, Treble center freq, SUB filter, SUB phase, Bass Q-factor.

3.  Press the

 buttons on the panel or

9

/

:

 buttons on the RC touch

the desired button on the screen to enter the list of values.

4.  Press the

 buttons on the panel or

8

/   buttons on the RC touch

the desired button on the screen to select the desired value.

5.  Press PLAY/PAUSE / ENTER / SCAN button to confirm.

Bass center frequency:

 select the Bass center frequency according to the audio source disc: 60 Hz, 80 Hz, 100

Hz, 130 Hz, 150 Hz, 200 Hz.

Treble center frequency:

 select the Treble center frequency according to the audio source disc: 10 KHz, 12.5

KHz, 15 KHz, 17 KHz.

Sub filter:

 set a cut-off frequency of the subwoofer s LPF (low pass filter) and that of the  Small  speakers  HPF

(high pass filter). Crossover frequency setting has no effect if the subwoofer is set OFF and any other speaker set
is  Large .
Select a crossover frequency: 80 Hz, 120 Hz, 160 Hz.
