19

Operation

When you enter color setting menu,

following interface will be displayed:

1

2

3

4

1. Parameter list. Touch a parameter to

select it. Saturation, brightness, contrast,
sharpness and hue are available for
adjustment.

2. Increase/decrease buttons. Touch to

increase or decrease the value.

3. Touch to reset your adjustment to default

values.

4. Touch to quit color setting.
You can also press cursor buttons on the RC

to select and adjust parameters.

DVD setup

Press SETUP button on the RC to go to

DVD setup menu. Press cursor buttons on
the RC to select parameters and options for
adjustment, press ENTER button to confirm
your selection. You can also touch needed
items on the screen as follows:

1

2 3

1. Parameter list. Touch a parameter to

select it.

2. Touch to select 1 or 2 menu page.
3. Option list button. Touch to open option

list for corresponding parameter.

Following parameters are available for

adjustment:

•  OSD lang: Select on-screen display

language.

•  Subtitle lang: Select a DVD subtitle

language.

•  Audio lang: select a language of the DVD

audio.

•  DVD menu lang: Select a language of the

DVD menu.

•  Password: In order to make the Rating

feature work, the password mode must be
turned on. If you want to set the ratings limit,
you will need to enter the default password,
which is 0000, then press ENTER to confirm.
To change the password, enter the Password
change submenu. If you change the password,
the default password 0000 will be void.

•  Rating: The Rating control level is for

parents to control playing content and protect
your children from violence and erotic. The
disc, the level of which is higher than the
setting level can not be played.

•  TV shape: Select 4:3/PS (the wide-screen

image shows on the full screen, but some
part is cut off), 4:3/LB (the wide-screen image
shows and black bars appear on the top and
bottom of screen), Wide (wide-screen image is
shown).

•  NTSC/PAL: Select color system NTSC or

PAL.

•  Default: Reset to the initial factory settings.

Play/pause

The unit will automatically play from the first

sound track recorded on a disc/SD/MMC/USB
device. To ensure good system performance,
wait until the unit finishes reading the disc/
device information before proceeding. Press

 button on the RC or 3/

 button on the

panel to pause playback, press it again to
resume playback.
