Operation

14

selected PTY is searched. During 1
loop, if desired PTY is not found, the
unit will return to previous mode.

USB/SD/MMC operations

Connecting a USB/Memory

card

Insert a USB device into the USB

port of this unit (remove the rubber
cover first). Detach the front panel and
insert an SD/MMC memory card until
a click into the memory card slot. If
you want to remove the card, detach
the front panel, press the card until
a click, then pull to remove. Always
switch the unit to another operation
mode before disconnecting USB/
memory card from the slot.

  USB/SD/MMC supported

capacity: up to 16 Gb. FAT16/FAT32
file systems are supported.

For correct and satisfactory

operation, licensed SD/MMC memory
cards of famous brands should
be used with this unit. Avoid using
memory cards of unknown brands.
Some models of According to the
USB 1.1/2.0 Standard, usage of
a USB device with power current
consumption exceeding 500 mA
is not recommended without
supplementary power supply. Failure
to use supplementary power for
connected USB drives with power
consumption exceeding this value
as well as defective USB drives may
cause mechanical or thermal changes
of elements of this unit or failure of
internal elements of USB port. Such
damages are not warrantee cases.

Warning:

 usage of external USB

drives containing BIN files in the root
directory may cause malfunction of
the unit or damage to the software.

Playback

•  When a USB or a memory card

is first connected, playback will begin
automatically. Depending on the
number of files and folders, the device
may take several seconds to begin
playback.

•  While playback, press BND/

TYPE button on the panel or RC to
switch between audio, video or photo
playback.

Track select

•  Press

 button to skip to the

beginning of the next track. Press

button to skips to the previous track.

•  Press   button on the panel or

 button on the RC once; the display

will show the list of files of currently
played format (video, audio or photo).
Rotate VOLUME knob on the panel
or press UP/DOWN cursor buttons on
the RC to select a file. Press SELECT
button on the panel or OK button on
the RC to play the selected file.

•  In audio playback mode press

LIST button, then rotate VOLUME
knob on the panel or press UP/DOWN
cursor buttons on the RC to select an
audio track.

Fast forward/rewind

Press and hold

 or

 button

to rewind or fast forward the current
track. Press APS/

 button on the

panel or

 button on the RC to

return to normal playback.
