Hyundai Electronics H-CCR4702M - Инструкция по эксплуатации - Страница 10

10

Operation

Remote controller (RC)

1

2

3

4

5

6
7

8

9

10

12

13

14

15

16

17

18

19

20

21

22

23

11

GO TO

1. MENU button
2. PWR/MUTE button
3. UP cursor button
4. MODE button
5. ENTER button
6.

 button

7. DOWN cursor button
8. RPT button
9. MOVIE/TA button
10. MUSIC/AF button
11. Digit buttons
12.

 button

13. OPEN button
14. AUDIO button
15. SUB-T button
16.

 button

17. VOL+ button
18. SEL button

19. VOL- button
20. PHOTO/PTY button
21. ZOOM/GO TO button
22. SCALE/ROTATE button
23. TILT button

Changing the battery

1. Press the catch and at the same time pull

out the battery tray.

2. Insert the 1 lithium battery, type CR2025

(3 V) battery with the stamped (+) mark facing
upward. Insert the battery tray into the remote
controller.

  •  Store the battery where children

cannot reach. If a child accidentally swallows
the battery, consult a doctor immediately.

•  Do not recharge, short, disassemble or

heat the battery or dispose it in a fire.

•  Do not expose or bring into contact the

battery with other metallic materials. Doing this
may cause the battery to give off heat, crack or
start a fire.

•  When throwing away or saving the battery,

wrap it in tape and insulate; otherwise, the
battery may give off heat, crack or start a fire.

•  Please direct the Remote controller to the

IR sensor of the front panel.

General operations

Touch screen

Due to the touch screen, you can fulfill most

functions not only by pressing buttons but also
by touching the options you need.

Turning the unit on/off

Press PWR/MUTE button  on the front panel

or on the RC to turn the unit on. Press and hold
PWR/MUTE button on the front panel or on the
RC to turn the unit off.

Reset the unit

Operating the unit for the first time or after

replacing the car battery, you must reset the
