7.1 Chip blower

Optional blower for a clear view of the cutting line.

On

:Press the switch button (11) on the left side of

the machine. (look for the

 symbol).

Off:

Press the switch button (11) on the right side of

the machine. (look for the

 symbol).

7.2 Adjusting the pendulum motion

Set the required pendulum motion using the

adjustment lever (10).

Position "0"

 = pendulum motion is switched off

. . .

Position "III"

 = maximum pendulum motion

See page 3 for recommend setting values.
The best way to determine the ideal setting is

through a practical trial.

7.3 Setting maximum speed

Set the machine to maximum speed using the

setting wheel (15). This can also be done during

operation.
See page 3 for recommend setting values.
The best way to determine the ideal setting is

through a practical trial.

7.4 On/Off switch, continuous activation

Avoid inadvertent starts: always switch the

tool off when the plug is removed from the

mains socket or if there has been a power cut.

In continuous operation, the machine

continues running if it is forced out of your

hands. Therefore always hold the machine with

both hands using the handle provided, stand

securely and concentrate.

Switching on:

push the sliding switch (12)

forwards. For continuous operation, now tilt it

downwards until it engages.

Switching off:

 press the rear end of the slide switch

(12) and release it.

Clean the machine regularly.

 This includes

vacuum cleaning the ventilation louvres on the

motor.
Clean the saw blade clamping fixture (2) regularly

and thoroughly by blowing with compressed air.
If necessary, clean the openings behind the saw

blade support roller (3).
Apply a drop of oil to the saw blade support roller (3)

from time to time.

Plunging

The jigsaw blade can plunge into workpieces made

from thin, soft materials without the necessity of

drilling a hole beforehand. Only use short saw

blades. Only at 0° angle setting.

See illustration on page 2. Set the adjustment lever

(10) to the "0" position (pendulum motion is

deactivated). Position the jigsaw with the front edge

of the footplate (6) on the workpiece. Hold the

operating jigsaw firmly and guide slowly

downwards. Once the saw blade has penetrated

the workpiece, the pendulum motion can be

activated.
In thicker workpieces, a hole for inserting the saw

blade must be drilled first.

Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements

and specifications listed in these operating

instructions.
Fit accessories securely. If the machine is operated

in a holder: secure the machine well. Loss of control

can cause personal injury.
See page 4.

A Circular-cutting and parallel guide

B Protective plate (prevents workpieces with

sensitive surfaces from becoming scratched)

10.1 Attaching the circular-cutting and

parallel guide

For sawing circles (dia. 100 - 360 mm) and making

cuts parallel with edges (max. 210 mm).

Attach circular guide

 (see Fig. I)

- Slide the rod on the circular-cutting and parallel

guide sideways into the footplate (centre point (c)

faces downwards).

- Set the desired radius (d).

- Tighten screw (b).

- Turn the button in such a way that the rear centre

point (c) in direction of sawing is extended. Insert

it into the centre of the circle.

Attach parallel guide

 (see Fig. II)

- Slide the rod on the circular cutting and parallel

guide sideways into the footplate

(the centre point (c) faces upwards).

- Set the dimension (e)

- Tighten screw (b).

In order to minimise saw blade drifting, we

recommend using extra-thick saw blades:

 6.23694

,

6.23679, 6.23685

For a complete range of accessories, see

www.metabo.com or the catalogue.

Repairs to electrical tools must ONLY be

carried out by qualified electricians!

Contact your local Metabo representative if you

have Metabo power tools requiring repairs. See

www.metabo.com for addresses.
You can download a list of spare parts from

www.metabo.com.
