Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits.

- Use an extraction unit and/or air purifiers.

- Ensure good ventilation of the workplace and

keep clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

See page 2.

1 Clamping lever for securing the saw blade

2 Saw blade clamping fixture

3 Saw blade support roller

4 Saw blade *

5 Screw for adjusting the footplate

6 Footplate

7 Anti-splintering footplate insert *

8 Protective rod for preventing unintentional

contact with the saw blade

9 Protective  cap

10 Adjustment lever for pendulum motion

11 Switch button on the chip blower

12 Slide switch

13 Handle

14 Extractor connection piece *

15 Setting wheel for speed adjustment

16 Hexagon spanner

17 Wrench depot

18 Curved support plate indicating preset cutting

angle

* depending on equipment/not in scope of delivery

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

type plate match your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream.
Never operate the machine without a saw

blade.
Pull the plug out of the socket before making

any adjustments, changing tools, carrying out

maintenance or cleaning.

6.1 Fitting the anti-splintering footplate

insert

Danger of injury due to the sharp jigsaw blade.

Remove the saw blade before fitting the anti-

splintering footplate insert (7).
Turn the machine over so that the footplate faces

upwards. Insert the anti-splintering footplate from

the front, while noting the following 2 items:

•

The smooth side of the footplate points upward.

•

The slot is facing to the rear (towards the mains

cable).

If you wish to work with the protective plate attached

(see chapter Accessories 10.), insert the anti-

splintering footplate insert in the protective plate.

6.2 Inserting the saw blade

Danger of injury due to the sharp jigsaw blade.

After stopping work, the jigsaw blade may still

be hot. Wear protective gloves.
Use a saw blade that is suitable for the material

being sawn.
- Turn the clamping lever (1) forwards to the stop

and hold in place.

- Insert the saw blade (4) up to the stop. Ensure that

the saw teeth are facing forwards and the blade is

seated correctly in the groove on the saw blade

support roller (3).

- Release the clamping lever (1). (It returns to its

initial position by itself. The saw blade is now

securely tightened).

6.3 Removing the saw blade

Caution: Be careful not to point the jigsaw at

anyone when removing it.

- Turn the clamping lever (1) forward until the stop;

the saw blade is ejected as a result of spring force.

6.4 Sawing with dust extraction

- Fit the extractor connection piece (14). Connect a

suitable extraction device.

- For optimum dust extraction performance, push

the protective cap (9) downward.

- Switch off the chip blower

(see chapter 7.1).

6.5 Sawing without dust extraction

- Work with the protective cap (9) pushed up.

6.6 Diagonal cuts

Push the protective cap (9) upwards, remove the

anti-splintering footplate  (7). These parts cannot be

used for diagonal cuts.
- Slacken the screw (5).

- Slid the footplate (6) forwards slightly and turn.

- Subsequently push the footplate insert (6)

towards the back into one of the notches (45°

angle, 0° angle). The preset angle is indicated on

the curved support plate (18) on the footplate.

Adjust to different angles using an angle gage.

- Tighten the screw (5) again.

6.7 Sawing close to the wall

Push the protective cap (9) upwards, remove the

anti-splintering footplate insert (7), circular-cutting

and parallel guide. These parts cannot be used

when sawing close to the wall.
- Slacken the screw (5) until the footplate (6) can be

raised slightly.

- Raise the footplate (6) slightly and slide

backwards up to the stop.

- Tighten the screw (5) again.

5. Overview

6. Initial Operation
