9 ENGLISH

FUNCTIONAL

DESCRIPTION

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery

cartridge

CAUTION:

Always switch off the tool before

installing or removing of the battery cartridge.

CAUTION:

Hold the tool and the battery cartridge

firmly when installing or removing battery cartridge.

Failure to hold the tool and the battery cartridge firmly may

cause them to slip off your hands and result in damage to

the tool and battery cartridge and a personal injury.

►

Fig.1:

1.

 Red indicator

2.

 Button

3.

 Battery cartridge

To remove the battery cartridge, slide it from the tool

while sliding the button on the front of the cartridge.

To install the battery cartridge, align the tongue on the

battery cartridge with the groove in the housing and slip

it into place. Insert it all the way until it locks in place

with a little click. If you can see the red indicator on the

upper side of the button, it is not locked completely.

CAUTION:

Always install the battery cartridge

fully until the red indicator cannot be seen.

 If not,

it may accidentally fall out of the tool, causing injury to

you or someone around you.

CAUTION:

Do not install the battery cartridge

forcibly.

 If the cartridge does not slide in easily, it is

not being inserted correctly.

Tool / battery protection system

The tool is equipped with a tool/battery protection sys

-

tem. This system automatically cuts off power to the

motor to extend tool and battery life. The tool will auto

-

matically stop during operation if the tool or battery is

placed under one of the following conditions:

Overload protection

When the battery is operated in a manner that causes

it to draw an abnormally high current, the tool automat-

ically stops without any indication. In this situation, turn

the tool off and stop the application that caused the tool

to become overloaded. Then turn the tool on to restart.

Overheat protection

When the tool or battery is overheated, the tool stops

automatically and the lamp blinks. In this case, let the

tool and battery cool before turning the tool on again.

Overdischarge protection

When the battery capacity is not enough, the tool stops

automatically. If you turn the tool on, the motor runs

again but stops soon. In this case, remove the battery

from the tool and charge the battery.

Indicating the remaining battery

capacity

Only for battery cartridges with the indicator

►

Fig.2:

1.

 Indicator lamps

2.

 Check button

Press the check button on the battery cartridge to indi-

cate the remaining battery capacity. The indicator lamps

light up for a few seconds.

Indicator lamps

Remaining

capacity

Lighted

Off

75% to 100%

50% to 75%

25% to 50%

0% to 25%

NOTE:

 Depending on the conditions of use and the

ambient temperature, the indication may differ slightly

from the actual capacity.

Selecting the cutting action

►

Fig.3:

1.

 Cutting action changing lever

This tool can be operated with an orbital or a straight

line (up and down) cutting action. The orbital cutting

action thrusts the jig saw blade forward on the cutting

stroke and greatly increases cutting speed.

To change the cutting action, just turn the cutting action

changing lever to the desired cutting action position.

Refer to the table to select the appropriate cutting

action.

Position

Cutting action

Applications

0

Straight line cutting

action

For cutting mild

steel, stainless

steel and plastics.
For clean cuts in

wood and plywood.

I

Small orbit cutting

action

For cutting mild

steel, aluminum

and hard wood.

II

Medium orbit

cutting action

For cutting wood

and plywood.
For fast cutting in

aluminum and mild

steel.

III

Large orbit cutting

action

For fast cutting in

wood and plywood.

Switch action

To turn on the tool, press the lock/unlock button. The

tool turns into the standby mode. To start the tool, pull

the switch trigger in the standby mode. To stop the

tool, release the switch trigger. The tool turns into the

standby mode. To turn off the tool, press the lock/unlock

button in the standby mode.
