Rip fence

Optional accessory

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed

before installing or removing accessories.

Straight cuts

When repeatedly cutting widths of 160 mm or less, use

of the rip fence will assure fast, clean, straight cuts.

►

Fig.23:

1.

 Rip fence (Guide rule)

To install, insert the rip fence into the rectangular hole

on the side of the base with the fence guide facing

down. Slide the rip fence to the desired cutting width

position, then tighten the bolt to secure it.

►

Fig.24:

1.

 Hex wrench

2.

 Bolt

3.

 Fence guide

4.

 Rip

fence (Guide rule)

Circular cuts

When cutting circles or arcs of 170 mm or less in radius,

install the rip fence as follows.

►

Fig.25:

1.

 Rip fence (Guide rule)

1.

  Insert the rip fence into the rectangular hole on the

side of the base with the fence guide facing up.

2.

  Insert the circular guide pin through either of the

two holes on the fence guide. Screw the threaded knob

onto the pin to secure the pin.

►

Fig.26:

1.

 Threaded knob

2.

 Fence guide

3.

 Rip

fence (Guide rule)

4.

 Pin

3.

Slide the rip fence to the desired cutting radius,

and tighten the bolt to secure it in place. Then move the

base all the way forward.

NOTE:

 Always use jig saw blades No. B-17, B-18,

B-26 or B-27 when cutting circles or arcs.

Anti-splintering device

Optional accessory

CAUTION:

The anti-splintering device cannot

be used when making bevel cuts.

►

Fig.27:

1.

 Base

2.

 Anti-splintering device

For splinter-free cuts, the anti-splintering device can

be used. To install the anti-splintering device, move the

tool base all the way forward and fit it from the back of

tool base.

When you use the cover plate, install the anti-splintering

device onto the cover plate.

Cover plate

Optional accessory

►

Fig.28:

1.

 Cover plate

2.

 Base

Use the cover plate when cutting decorative veneers,

plastics, etc. It protects sensitive or delicate surfaces

from damage. Fit it on the back of the tool base.

Guide rail adapter set

Optional accessory

When cutting parallel and uniform width or cutting

straight, the use of the guide rail and the guide rail

adapter will assure the production of fast and clean

cuts. To install the guide rail adapter, insert the rule

bar into the square hole of the base as far as it goes.

Secure the bolt with the hex wrench securely.

►

Fig.29:

1.

 Hex wrench

2.

 Rule bar

Insert the rule bar into the square hole of the guide rail

adapter, and secure the screw firmly. Place the guide

rail adapter on the guide rail.

►

Fig.30:

1.

 Guide rail adapter

2.

 Guide rail

3.

 Screw

NOTICE:

 Always use blades No. B-8, B-13, B-16, B-17

or 58 when using the guide rail and the guide rail adapter.

MAINTENANCE

CAUTION:

Always be sure that the tool is

switched off and the battery cartridge is removed before

attempting to perform inspection or maintenance.

NOTICE:

Never use gasoline, benzine, thinner,

alcohol or the like. Discoloration, deformation or

cracks may result.

To maintain product SAFETY and RELIABILITY,

repairs, any other maintenance or adjustment should

be performed by Makita Authorized or Factory Service

Centers, always using Makita replacement parts.

OPTIONAL

ACCESSORIES

CAUTION:

These accessories or attachments

are recommended for use with your Makita tool spec-

ified in this manual.

 The use of any other accessories

or attachments might present a risk of injury to persons.

Only use accessory or attachment for its stated purpose.

If you need any assistance for more details regarding

these accessories, ask your local Makita Service Center.

•

Jig saw blades

•

Hex wrench 3

•

Rip fence (guide rule) set

•

Guide rail adapter set

•

Anti-splintering device

•

Hose (For vacuum cleaner)

•

Cover plate

•

Dust nozzle

•

Dust cover

•

Makita genuine battery and charger

NOTE:

 Some items in the list may be included in the

tool package as standard accessories. They may

differ from country to country.
