 CAUTION:

• Do not open the tool opener excessively, or it may

cause tool damage.

 (Fig. 7)

To remove the blade, push the tool opener forward as far
as it will go. This allows the blade to be released.

NOTE:

• Occasionally lubricate the roller.

Hex wrench storage (Fig. 8)

When not in use, store the hex wrench as shown in the
figure to keep it from being lost.

Cover plate (Fig. 9)

Use the cover plate when cutting decorative veneers,
plastics, etc. It protects sensitive or delicate surfaces from
damage. Fit it on the back of the tool base.

Anti-splintering device (Fig. 10)

For splinter-free cuts, the anti-splintering device can be
used. To install the anti-splintering device, move the tool
base all the way forward and fit it from the back of tool
base. When you use the cover plate, install the anti-
splintering device onto the cover plate.

 CAUTION:

• The anti-splintering device cannot be used when

making bevel cuts.

Dust extraction

The dust nozzle (optional accessory) is recommended to
perform clean cutting operations.

 (Fig. 11)

To attach the dust nozzle on the tool, insert the hook of
dust nozzle into the hole in the base.

 (Fig. 12)

To secure the dust nozzle, tighten the clamp screw at the
front of the dust nozzle.
The dust nozzle can be installed on either left or right side
of the base.

 (Fig. 13)

Then connect a Makita vacuum cleaner to the dust
nozzle.

OPERATION

 CAUTION:

• Always hold the base flush with the workpiece. Failure

to do so may cause blade breakage, resulting in a
serious injury.

NOTE:

• If the tool is operated continuously until the battery

cartridge has discharged, allow the tool to rest for
15 minutes before proceeding with a fresh battery.

(Fig. 14)

Turn the tool on without the blade making any contact and
wait until the blade attains full speed. Then rest the base
flat on the workpiece and gently move the tool forward
along the previously marked cutting line.
When cutting curves, advance the tool very slowly.

Bevel cutting (Fig. 15)

 CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before tilting the base.

With the base tilted, you can make bevel cuts at any angle
between 0° and 45° (left or right).

 (Fig. 16)

To tilt the base, loosen the bolt on the back of the base
with the hex wrench. Move the base so that the bolt is
positioned in the center of the bevel slot in the base.

(Fig. 17)

Tilt the base until the desired bevel angle is obtained. The
V-notch of the gear housing indicates the bevel angle by
graduations. Then tighten the bolt firmly to secure the
base.

Front flush cuts (Fig. 18)

Loosen the bolt on the back of the base with the hex
wrench and slide the base all the way back. Then tighten
the bolt to secure the base.

Cutouts

Cutouts can be made with either of two methods A or B.

A) Boring a starting hole: (Fig. 19)

• For internal cutouts without a lead-in cut from an edge,

pre-drill a starting hole 12 mm or more in diameter.
Insert the blade into this hole to start your cut.

B) Plunge cutting: (Fig. 20)

• You need not bore a starting hole or make a lead-in cut

if you carefully do as follows.

1. Tilt the tool up on the front edge of the base with the

blade point positioned just above the workpiece
surface.

2. Apply pressure to the tool so that the front edge of the

base will not move when you switch on the tool and
gently lower the back end of the tool slowly.

3. As the blade pierces the workpiece, slowly lower the

base of the tool down onto the workpiece surface.

4. Complete the cut in the normal manner.

Finishing edges (Fig. 21)

To trim edges or make dimensional adjustments, run the
blade lightly along the cut edges.

Metal cutting

Always use a suitable coolant (cutting oil) when cutting
metal. Failure to do so will cause significant blade wear.
The underside of the workpiece can be greased instead of
using a coolant.

Rip fence set (optional accessory)

 CAUTION:

• Always be sure that the tool is switched off and the

battery cartridge is removed before installing or
removing accessories.

1. Straight cuts (Fig. 22)

When repeatedly cutting widths of 160 mm or less, use of
the rip fence will assure fast, clean, straight cuts.

 (Fig. 23)

To install, insert the rip fence into the rectangular hole on
the side of the tool base with the fence guide facing down.
Slide the rip fence to the desired cutting width position,
then tighten the bolt to secure it.

2. Circular cuts (Fig. 24 & 25)

When cutting circles or arcs of 170 mm or less in radius,
install the rip fence as follows.
