English |

17

LED

Capacity

Continuous lighting 3x green

≥2/3

Continuous lighting 2x green

≥1/3

Continuous lighting 1x green

<1/3

Flashing light 1x green

Reserve

Flashing light 3x green

Empty

If no LED lights up after switching the power tool on, then
the battery is defective and must be replaced.

Inserting/changing the saw blade

u

When fitting or changing the saw blade, wear protect-
ive gloves.

 Blades are sharp and can become hot when

used for prolonged periods of time.

Selecting the saw blade

You will find an overview of recommended saw blades at the
end of these operating instructions. Only use saw blades
with single lug shank (T shank). The saw blade should not be
longer than required for the intended cut.
Use a narrow saw blade when sawing tight curves.

Inserting the saw blade (see figure B)

u

Clean the shaft on the saw blade before inserting it.

A dirty shaft cannot be securely fixed in place.

Push the saw blade

(13)

, with the teeth in the cutting direc-

tion, into the saw blade receptacle

(11)

 until it clicks into

place. The SDS lever

(20)

 automatically springs back and

the saw blade is locked in place. Do not push the lever

(20)

back by hand as you could damage the power tool.
Make sure when inserting the saw blade that the back of the
saw blade is in the groove on the guide roller

(10)

.

u

Check that the saw blade is seated securely.

 A loose

saw blade can fall out and lead to injuries.

Ejecting the saw blade (see figure C)

u

When ejecting the saw blade, hold the power tool in
such a manner that no persons or animals can be in-
jured by the ejected saw blade.

Turn the SDS lever

(20)

 as far as it will go in the direction of

the shock protection guard

(21)

. The saw blade is released

and ejected.

Glide shoe (see figure D)

When machining sensitive surfaces, you can place the glide
shoe

(17)

 on the base plate

(9)

 in order to prevent the sur-

face from being scratched.
To position the glide shoe

(17)

, hook it to the front of the

base plate

(9)

, push it up at the back and allow it to click into

place.

Anti-splinter guard (see figure E)

The anti-splinter guard

(18)

 (accessory) can prevent splin-

tering of the surface while sawing wood. The anti-splinter
guard can only be used with certain saw blade types and only
at a cutting angle of 0°.

Slide the anti-splinter guard

(18)

 into the base plate

(9)

from the front.
When using the glide shoe

(17)

, the anti-splinter guard

(18)

is inserted into the glide shoe rather than the base plate

(9)

.

Dust/Chip Extraction

The dust from materials such as lead paint, some types of
wood, minerals and metal can be harmful to human health.
Touching or breathing in this dust can trigger allergic reac-
tions and/or cause respiratory illnesses in the user or in
people in the near vicinity.
Certain dusts, such as oak or beech dust, are classified as
carcinogenic, especially in conjunction with wood treatment
additives (chromate, wood preservative). Materials contain-
ing asbestos may only be machined by specialists.
– Use a dust extraction system that is suitable for the ma-

terial wherever possible.

– Provide good ventilation at the workplace.
– It is advisable to wear a P2 filter class breathing mask.
The regulations on the material being machined that apply in
the country of use must be observed.

u

Avoid dust accumulation at the workplace.

Dust can

easily ignite.

Hood

Fit the hood

(15)

 before you connect the power tool to the

dust extraction system.
Attach the hood

(15)

 to the power tool so that the bracket

locks into place on the shock protection guard

(21)

.

Remove the hood

(15)

 when working without a dust extrac-

tion system and for mitre/bevel cuts. To do this, pull the
hood forwards off the shock protection guard

(21)

.

Connecting the dust extraction (see figures F–G)

Fit the extraction outlet

(16)

 in the recesses of the base

plate

(9)

.

Connect a dust extraction hose

(22)

 (accessory) to the ex-

traction outlet

(16)

. Connect the dust extraction hose

(22)

to a dust extractor (accessory).
You will find an overview of connecting to various dust ex-
tractors at the end of these operating instructions.
For optimum dust extraction, where possible use the anti-
splinter guard

(18)

.

The dust extractor must be suitable for the material being
worked.
When extracting dry dust that is especially detrimental to
health or carcinogenic, use a special dust extractor.

Operation

Operating modes

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.
