16

 | English

(21)

Shock protection guard

(22)

Extraction hose

A)

(23)

Base plate screw

(24)

Hex key

(25)

Scale for mitre/bevel angles

(26)

Locking screw for parallel guide

A)

(27)

Parallel guide with circle cutter

A)

(28)

Circle cutter centring tip

A)

A)

Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.

Technical Data

Cordless jigsaw

GST 12V-70

Article number

3 601 EA1 0..

Rated voltage

V=

12

No-load stroke rate n

0

min

−1

1500–2800

Stroke

mm

18

Max. cutting depth

– In wood

mm

70

– In aluminium

mm

3

– In steel (unalloyed)

mm

3

Max. cutting angle (left/
right)

°

45

Weight according to
EPTA-Procedure 01:2014

kg

1.5–1.7

A)

Permitted ambient temperature

– during charging

°C

0 to +45

– during operation

B)

 and

during storage

°C

–20 to +50

Recommended batteries

GBA 12V…

Recommended chargers

GAL 12...

GAX 18...

A) Depends on battery in use
B) Limited performance at temperatures <0 °C

Technical data determined using the battery that comes with the
product.

Noise/Vibration Information

Noise emission values determined according to

EN 62841-2-11

.

Typically, the A-weighted sound pressure level of the power
tool is

75

 dB(A). Uncertainty K = 5 dB. The noise level when

working can exceed the volume stated.

 Wear hearing pro-

tection

Vibration total values a

h

 (triax vector sum) and uncertainty K

determined according to

EN 62841-2-11

:

Cutting boards with saw blade

T 111 C

:

a

h,B

 =

4.5

 m/s

2

, K =

1.5

 m/s

2

,

Cutting sheet metal with saw blade

T 118 A

:

a

h,M

 =

4.5

 m/s

2

, K =

1.5

 m/s

2

.

The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.

Assembly

u

Remove the battery from the power tool before carry-
ing out work on the power tool (e.g. maintenance,
changing tool, etc.). The battery should also be re-
moved for transport and storage.

 There is risk of injury

from unintentionally pressing the on/off switch.

Battery Charging (see figure A)

u

Use only the chargers listed in the technical data.

 Only

these chargers are matched to the lithium-ion battery of
your power tool.

Note:

The battery is supplied partially charged. To ensure

full battery capacity, fully charge the battery in the charger
before using your power tool for the first time.
The lithium-ion battery can be charged at any time without
reducing its service life. Interrupting the charging process
does not damage the battery.
The lithium-ion battery is protected against deep discharge
by the "Electronic Cell Protection (ECP)". When the battery
is discharged, the power tool is switched off by means of a
protective circuit: The application tool no longer rotates.

u

Do not continue to press the On/Off switch after the
power tool has automatically switched off.

 The battery

can be damaged.

To remove the battery

(1)

, press the release button

(2)

 and

pull the battery downwards out of the power tool.

Do not

use force to do this.

Battery charge indicator

The three green LEDs of the battery charge indicator

(4)

 in-

dicate the state of charge of the battery

(1)

. The battery

charge indicator only lights up for five seconds after start-
up.
