22 

en

Operation 

Warning!

The reversible slicing disc is not suitable for 

slicing hard cheese, bread, rolls or chocolate. 

Slice boiled, waxy potatoes only when they 

are cold.

Reversible shredding disc –

coarse / fine

for shredding vegetables, fruit and cheese, 

except for hard cheese (e.g. Parmesan).

Processing at setting 2 or 3.

Designation on the reversible shredding 

disc: 

“2” for the coarse shredding side 

“4” for the fine shredding side

Warning!

The reversible shredding disc is not suitable 

for shredding nuts. Shred soft cheese with 

the coarse side only at setting 4.

Grating disc – medium-fine

for grating raw potatoes, hard 

cheese (e.g. Parmesan), cooled chocolate 

and nuts.

Process at setting 4.

Warning!

The grating disc is not suitable for grating 

soft cheese and cheese slices.

Working with the continuous-feed

shredder

Fig.

G

:

■ Press the Release button and 

move the swivel arm to 

position 

2

.

■ Insert the bowl: 

Tilt the bowl forwards and then set it 

down. Turn anti­clockwise until it locks 

into place.

■ Press the Release button and 

move the swivel arm to 

position 

3

.

■ Remove drive cover from the drive of the 

continuous­feed shredder 

(Fig.

G

-5a)

.

■ Hold disc holder at the lower end, ensuring 

that the two tips are face up.

■ Carefully place the required slicing or 

shredding disc onto the tips of the disc 

holder 

(Fig.

G

-6a)

. 

In the case of reversible discs, ensure 

that the required side is face up.

■ Grip disc holder at the upper end and 

insert into the housing 

(Fig.

G

-6b)

.

■ Attach the cover (note mark) and turn all 

the way in a clockwise direction.

■ Place continuous­feed shredder on the 

drive and rotate all the way in a clockwise 

direction, as illustrated in 

Fig.

G

-8

.

■ Turn rotary switch to recommended 

setting.

■ Put food to be processed in the feed tube 

and push down with the pusher.

Warning!

Prevent the cut ingredients from building up 

in the outlet opening.

Tip:

 To ensure even cutting results, process 

thin ingredients in bunches.

Note:

 If the food to be processed sticks in 

the continuous­feed shredder, switch food 

processor off, pull out mains plug, wait until 

the drive comes to a standstill, remove 

cover from the continuous­feed shredder 

and empty feed tube.

After using the appliance

■ Switch off the appliance with the rotary 

switch.

■ Rotate the continuous­feed shredder in 

an anti­clockwise direction and remove.

■ Rotate the lid in an anti­clockwise 

direction and remove.

■ Remove disc holder with disc. To do this, 

press finger from below against the drive 

shaft 

(Fig.

H

)

.

■ Clean parts.

Blender

W

Risk of injury from sharp blades /

rotating drive!

Never place fingers in the attached blender! 

Do not remove / attach the blender until 

the drive is at a standstill! Operate the 

assembled blender only and with the lid 

attached.
