www.timberk.com • Electric air conditioner

www.timberk.com • Electric air conditioner

8

9

8. MAINTENANCE

«SUPER» mode (TURBO)

When pressing the «TURBO» button on the remote control board, the

conditioner will start working in turbo mode – for maximum cooling (in cool

mode) or for maximum heating (in heat mode).

TIMER mode

Procedure of timing:
– If the conditioner is off, then press the “TIMER” button to activate the

automatic turning on. Pressing this button once again, set the time for

turning the conditioner on in the set time interval. To cancel the timer mode,

press the “TIMER” button once again.
–If the conditioner is working, then press the “TIMER” button to activate

the automatic turning off. Pressing this button once again, set the time for

turning the conditioner off in the set time interval. To cancel the timer mode,

press the “TIMER” button once again.

«SLEEP» mode

Button «SLEEP» (Night Care). Using this button, you may turn the sleep

mode on and off. In this mode, if working for cooling, the conditioner will

increase temperature by 1 °С an hour  from the specified one within two

hours. If working for heating, the conditioner will decrease temperature by

1 °С an hour  from the specified one within two hours. After 10 hours of

operation the conditioner will turn off automatically.

Regulation of treated air flow direction

Regulating the position of deflectors (blinds), set the direction of treated

air flow ensuring uniform distribution of temperature and the most comfort

conditions in the room. To change the position of deflectors, use the

«SWING» button.

AUTO mode (SMART)

The auto mode is turned on and off with the use of the button “MODE” on

the remote control board.
1. While working in the AUTO mode, a microprocessor will automatically

select COOL, FAN, HEAT or DRY modes based on the difference between

actual and preset air temperature indoors.
2. If the AUTO mode does not provide comfort conditions, select the mode

manually. In automatic mode, depending on air temperature in the room,

the conditioner will select needed temperature parameters of its operation

in the following order:

7. OPERATING MODES

Temperature indoors

Automatic mode sele ction

Automatically maintained temperature

if <20° С

then HEAT mode shall be turned on

23° С

if <20° С - 26° С

then DRY mode shall be turned on

18° С

if <26° С

then COOL mode shall be turned on

23° С

ASmart mode allows changing threshold of switching from mode to mode.

During operation in Smart mode you see «-» on the display. Press keys

Temp +/-. «-» will change by +(-) 2. The range shift of this threshold
ASmart mode allows changing threshold of switching from mode to mode.

During operation in Smart mode you see «-» on the display. Press keys

Temp +/-. «-» will change by +(-) 2. The range shift of this threshold is within

-2...+2 of default temperatures.

COOL, HEAT and FAN

1. Turn the conditioner on pressing the «ON/OFF» button.
2. Pressing the «MODE» button, select COOL, HEAT or FAN mode

manually.
3. Pressing the «TEMP» button (up-down), set the desired air temperature

indoors (except for FAN mode).
4.Pressing the «FAN SPEED» button on the remote control board, select

the fan rotation speed: AUTO, LOW, MIDDLE, HIGH, and the conditioner

will start working in accordance with the selected setting. In the Smart

mode fan speed automatically selected.
5.To turn the conditioner off, press the «ON/OFF» button once again.

•

Before cleaning unplug the conditioner.

•

Cleaning of the indoor unit and remote control board:

•

Indoor unit and remote control board should be cleaned with a dry soft

cloth.

•

If the indoor unit is too unclean, moisten the cloth with cold water.

•

It  is prohibited to clean the remote control board with moist cloth.

•

In order to avoid the damage of paint or details of the conditioner, do not

clean it with brushes and do not leave them on the surface of indoor unit.

•

In order to avoid the damage of surface or deformation of the conditioner

details, do not clean it with petrol, solvents, cleaning powders or other

chemically active substances.

•

Before a sustained interruption in the conditioner work:

•

Turn the conditioner on for several hours in the FAN mode. It will allow

you to dry its inner cavities

•

Unplug the conditioner. Remove the batteries from the remote control

board.

•

Checks before starting:

•

 Make sure that an air filter is installed.

•

Make sure that air inlet and outlet grilles of the outdoor unit are not

blocked by foreign objects.

•

Cleaning of air filter

•

Air filter cleans the air entering the conditioner from dust and foreign

particles. If the filter is contaminated, the conditioner capacity decreases

sharply.

•

If the conditioner is operated permanently, the filter should be cleaned

once per two weeks.

•

If the conditioner is installed in a room with dusty atmosphere, then the

air filter should be cleaned more often.

•

To remove the filter, open the indoor unit panel.

•

Remove air filters. Clean the filter with a vacuum cleaner or rinse it in

clean water. If the filter is contaminated heavily, clean it with a soft brush

and wash in diluted washing solution, then dry it in a cool place.

•

While cleaning the filter with the vacuum cleaner, hold it with contaminated

surface up. While washing the filter in water, hold it with contaminated

surface down.

•

Do not dry the filter in the sun or near a fire.

•

Set the air filter to initial position and close the panel.

In the FAN mode air temperature indoors is not set.

DRY

Turn the conditioner on pressing the «ON/OFF» button. Pressing the

«MODE» button, select the DRY mode. The conditioner will start working

in the set mode. To turn the conditioner off, press the «ON/OFF» button

once again.

9. TROUBLESHOOTING

In case of emergency, please, use the troubleshooting methods shown in

tables. If it is impossible to solve problems with these methods, apply to

the service center.
Failures and their possible reasons:

Failure

Possible reason

Actions

The conditioner does

not work

Interruptions in power supply

Wait for restoration of power
supply

Batteries in the remote control
board are low

Replace the batteries

Time of tuming on is set by
the timer

Wait till the conditooner turns
on by the timer or cancel the
timer setting

Insufficient cooling or

heating capacity

The set air temperature is too
high or too low

Set the air temperature
correctly

The air filter is clogged with dust

Clean the air filter

Foreign objects block the air intel
and retum air grillages of the
outdoor unit

Remove foreign objects

The conditioner works,

but does not cool or

heat the room

A three-minute delay of
compressor tuming on

Wait a little

The air temperature is set
incorrectly

Set the temperature correctly
