3. SPECIFICATIONS

Model

AC TIM 07H S18A

AC TIM 09H S18A

AC TIM 12H S18A

AC TIM 18H S18A

AC TIM 24H S18A

AC TIM 30H S18A

Indoor unit

AC TIM 07H S18A

AC TIM 09H S18A

AC TIM 12H S18A

AC TIM 18H S18A

AC TIM 24H S18A

AC TIM 30H 18A

Outdoor unit

AC TIM 07H S18A-01

AC TIM 09H S18A-01

AC TIM 12H S18A-01

AC TIM 18H S18A-01

AC TIM 24H S18A-01 AC TIM 30H S18A-01

Capacity (cooling)  BTU (kW)

7050 (2,196)

9560 (2,666)

12260 (3,596)

18680 (5,479)

24280 (7,112)

28980 (8,493)

Capacity (heating)  BTU (kW)

7850 (2,3027)

9250 (2,7086)

12750 (3,7332)

19000 (5,5665)

24500 (7,18)

28960 (8,4848)

Rated power consumption (cooling)

(W)

684

831

1120

1779

2347

2646

Rated power consumption (heating)

(W)

638

750

1095

1542

2106

2350

Power supply, V/Hz

220-240~/50

220-240~/50

220-240~/50

220-240~/50

220-240~/50

220-240~/50

Rated power current (cooling/

heating) (W)

3,19/2,98

3,85/3,48

5,17/5,04

8,23/7,2

10,91/9,76

12,27/10,9

Air circulation (indoor unit) m

3

/h

430

430

530

780

780

1000

Air circulation (outdoor unit) m

3

/h

1415

1415

2040

2340

3350

3350

Noise level (indoor unit) dB(A)

32/30/28

34/32/30

37/34/32

43/41/39

43/41/39

49/47/45

Noise level (outdoor unit) dB(A)

47

49

53

56

58

59

Refrigerant

R410A

R410A

R410A

R410A

R410A

R410A

Energy efficiency (cooling/heating)

I class

I class

I class

I class

I class

I class

Electrical protection class

A/A

A/A

A/В

В/A

В/В

A/A

Degree of protection against

moisture (indoor unit)

IPX0

IPX0

IPX0

IPX0

IPX0

IPX0

Degree of protection against

moisture (outdoor unit)

IPX4

IPX4

IPX4

IPX4

IPX4

IPX4

Model

AC TIM 07H S18A

AC TIM 09H S18A

AC TIM 12H S18A

AC TIM 18H S18A

AC TIM 24H S18A

AC TIM 30H S18A

Indoor unit

AC TIM 07H S18A

AC TIM 09H S18A

AC TIM 12H S18A

AC TIM 18H S18A

AC TIM 24H S18A

AC TIM 30H 18A

Outdoor unit

AC TIM 07H S18A-01

AC TIM 09H S18A-01

AC TIM 12H S18A-01

AC TIM 18H S18A-01

AC TIM 24H S18A-01 AC TIM 30H S18A-01

Refrigerant piping, Liquid side / Gas

side, (inch)

1/4 + 3/8

1/4 + 3/8

1/4 + 3/8

1/4 + 1/2

3/8 + 5/8

3/8 + 5/8

Max. refrigerant pipe length, m

15

15

15

15

15

15

 Maximum difference in level, m

5

5

5

5

5

5

Filling of Freon, g

+18 ~ +43

+18 ~ +43

+18 ~ +43

+18 ~ +43

+18 ~ +43

+18 ~ +43

Operating temperature range:

cooling, ° C

-7 ~ + 24

-7 ~ + 24

-7 ~ + 24

-7 ~ + 24

-7 ~ + 24

-7 ~ + 24

 Operating temperature range:

heating, ° C

430

510

630

1100

1300

1300

Net weight, indoor unit (kg)

6,5

6,5

7,0

9,0

9,0

14,0

Net weight, outdoor unit (kg)

19,2

21,5

28

33

46

52

Gross weight, indoor unit (kg)

8

8

9

12

12

17

Gross weight, outdoor unit (kg)

21

23,2

30

35

51

57

Net dimensions, indoor unit (mm)

718х240х180

718х240х180

770х240х180

900х280х202

900х280х202

1033х313х202

Net dimensions, outdoor unit (mm)

600х232х500

600х232х500

700х256х552

760х256х552

902х315х650

902х315х650

Packing dimensions, indoor unit

(mm)

805х305х255

805х305х255

855х305х255

985х365х298

985х365х298

1103х400х300

Packing dimensions, outdoor unit

(mm)

745х353х550

745х353х550

803х325х600

863х325х600

1028х430х705

1028х430х705
