En-5

● OPERATING INSTRUCTIONS ●

 AUTO mode (Auto change over)

The unit selects the operation mode according to the difference between the
room temperature and the set temperature. During AUTO mode, the unit
changes mode (COOL↔HEAT) when the room temperature is 2°C away
from the set temperature for more than 15 minutes.

Note:

Multi system operation

Two or more indoor units can be operated by one outdoor unit. When sev-
eral indoor units are operated simultaneously, the unit may not be able to
switch operation mode between COOL and HEAT. In this case, the indoor
unit becomes standby mode.

 COOL  mode

Enjoy cool air at your desired temperature.

Note:

Do not operate COOL mode at very low outside temperatures (less than
-10°C). Water condensed in the unit may drip and wet or damage furni-
ture, etc.

 DRY mode

Dehumidify your room. The room may be cooled slightly.
Temperature cannot be set during DRY mode.

 HEAT mode

Enjoy warm air at your desired temperature.

Operation indicator lamp

Emergency operation

When the remote controller cannot be used...

Emergency operation can be activated by pressing the emergency operation
switch (E.O.SW) on the indoor unit.

Each time the E.O.SW is pressed, the operation changes in
the following order:

1

Press

 to start the operation.

2

Press

 to select operation mode. Each press

changes mode in the following order:

3

Press

 or

 to set the temperature.

Each press raises or lowers the temperature by 1°C.

Press

 to stop the operation.

•  The same setting is selected the next time by simply pressing

.

Auto restart function

If a power failure occurs or the main power is turned off during operation, “Auto
restart function” automatically starts operation in the same mode as the one set

with

the remote controller

 just before the shutoff of the main power. When

timer is set, timer setting is cancelled and the unit starts operation when power
is resumed.

If you do not want to use this function, please consult the service repre-
sentative because the setting of the unit needs to be changed.

S

ELECTING OPERATION MODES

Set temperature : 24°C
Fan speed : Medium
Horizontal vane : Auto

(AUTO) (COOL) (DRY)  (HEAT)

Emergency COOL

Emergency HEAT

Stop

Note:

The fi rst 30 minutes of operation is test run. Temperature
control does not work, and fan speed is set to High.

Multi system operation

Two or more indoor units can be operated by one outdoor unit. When several
indoor units are operated simultaneously, cooling and heating operations can-
not be done at the same time. When COOL is selected with one unit and HEAT
with another or vice versa, the unit operated later becomes standby mode. The
power lamp blinks (display section).
