4.

Electric  air conditioner (split system)

EN

3.SPECIFICATIONS

Tab.1

Indoor unit
Outdoor unit

H-AR7-07H-UI134/I
H-AR7-07H-UI134/O

H-AR7-09H-UI135/I
H-AR7-09H-UI135/O

Capacity (cooling),  Btu/h (kW)

7500 (2.20)

9000 (2.63)

Capacity (heating), Btu/h (kW)

8000 (2.34)

9500 (2.78)

Rated power consumption (cooling) (W)

780

930

Rated power consumption (heating) (W)

730

860

Power supply V/Hz

220- 240~/50

220- 240~/50

Rated power current (cooling/heating) A

3,6/3,4

4,3/4,0

Air circulation (indoor unit) m

3

/h

500/400/340

520/420/340

Air circulation (outdoor unit) m

3

/h

1300

1400

Noise level (indoor unit) dB(A)

41/35/30

42/35/30

Noise level (outdoor unit) dB(A)

54

55

Refrigerant

R410A

R410A

Energy eiciency (cooling/heating)

C/C

C/C

Electrical protection class

I class

I class

Degree of protection against moisture

(indoor unit)

IPX0

IPX0

Degree of protection against moisture

(outdoor unit)

IPX4

IPX4

Refrigerant piping, Liquid side / Gas side,

(inch)

 1/4 / 3/8

 1/4 / 3/8

Max. refrigerant pipe length, m

20

20

Maximum diference in level, m

8

8

Filling of Freon, g

550

700

Operating temperature range: cooling, ° C

18

~43

18

~43

Operating temperature range:  heating, ° C

-7~24

-7~24

Net weight, indoor unit (kg)

7,0

7,0

Net weight, outdoor unit (kg)

20,6

23,0

Gross weight, indoor unit (kg)

8,6

8,7

Gross weight, outdoor unit (kg)

22,5

24,8

Net dimensions, indoor unit (mm)

715×188×250

715×188×250

Net dimensions, outdoor unit (mm)

685×260×430

685×260×430

Packing dimensions, indoor unit (mm)

775x260x324

775x260x324

Packing dimensions, outdoor unit (mm)

795×345×495

795×345×495
