9.

EN

Electric air conditioner
portable type

NOTE:

In dehumidification mode, remove the rubber plug of the drainage

hose, install the respective drainage hose (not in the set).
Disconnect the air outlet hose, connect the drainage hose to the
drainage hole and drain water from the unit to ensure maximum

dehumidification efficiency.

To resume the operation, remove the rubber plug of the drainage

hose to drain water at first. After water is drained, turn the unit on,

the unit will resume operation

Fig. 7

6. MAINTENANCE

1.  When cleaning the air conditioner, do not use gasoline, solvents and other chemically active

substances.

2.  To avoid electric shock and damage to electrical components, do not pour water on the air

conditioner from a tap or a hose.

3.  Do not use the air conditioner if the power cord is damaged. On the subject of replacing a

damaged power cord, contact an authorized service center.

Air filter

Air filter clogging with dust particles impairs the air conditioner operation efficiency, therefore

clean the filter no less than once in two weeks.

Filter removal/installation

Remove the air filter in the direction, indicated by the arrow. Slightly push it and then take it out

from the device for cleaning. (See Fig. 8).

IMPORTANT!

Disconnect the unit from the mains prior to cleaning.
