11.

EN

Electric air conditioner
portable type

IMPORTANT!

At high humidity additional condensate removal will be required (P1

symbol will be shown on the display). In this case a condensate collec-
tion tank at the device’s base is used.
In this case follow the instructions given below.

When the condensate collection tank is filled up, water needs to be

drained, otherwise the unit will not operate. Condensate should be
drained by opening the lower plug at the device’s base (Fig. 9).
But air conditioners are also designed to remove condensate continu-
ously without a need for a regular moisture removal from the device.
To do so it is necessary to use the drainage hose (not in the set) and

perform the following procedure:

1.  Prepare the drainage hose for condensate removal;

2.  Remove the plug from the back side of the device;

3.  Insert the drainage hose into the condensate drainage hole;

4.  Take the hose out to the drainage system to remove condensate;
A hole designed for continuous condensate removal in the center of
the device (Fig. 9) can be used for continuous condensate removal
under conditions of increased humidity inside a room.
To do so it is also necessary to perform the abovementioned proce-
dure.

ELECTRIC POWER SUPPLY

Make sure characteristics of the mains correspond to characteristics of the unit.

Insert the plug in the socket securely to avoid overheating and risk of fire.

Do not pull the power cord with excessive force: it may damage it.

Fig. 9
