3.TECHNICAL CHARACTERISTICS

Tab.1

Capacity (cooling)  kW

Capacity (heating) kW

Rated input (cooling) W

Rated input (heating) W

Voltage V/Hz

Rated current (cooling/heating) A

Air circulation (indoor unit) m3/h

Air circulation (outdoor unit) m3/h

Noise level (indoor unit) dB(A)

Noise level (outdoor unit) dB(A)

Refrigerant

Energy class (cooling/heating)

Electrical protection class

Degree of protection against
moisture (indoor unit)

Degree of protection against
moisture (outdoor unit)

Refrigerant piping, Liquid side /
Gas side, (inch)

Max. refrigerant pipe length, m

Maximum diference in level, m

Net weight, indoor unit (kg)

Net weight, panel (kg)

Net weight, outdoor unit (kg)

Gross weight, indoor unit (kg)

Gross weight, panel (kg)

Gross weight, outdoor unit (kg)

Net dimensions, indoor unit (mm)

Net dimensions of panel for indoor unit (mm)

Net dimensions, outdoor unit (mm)

Packing dimensions, indoor unit (mm)

Packing dimensions of panel for indoor unit (mm)

Packing dimensions, outdoor unit (mm)

3,52

3,81

1085

1235

220~240/50

5.2/5.3

680/600/400

2100

41/38/35

43

R410A

C/C

I class

IPX0

IP24

1/4 /1/2

15

8

16

2.5

28

20

 4.5

30

570x570x260

647x647x50

780x250x547

655x655x290

715x715x123

910x335x575

5,28

5,86

1834

1880

220~240/50

8.4/8.6

860/760/500

2439

44/41/38

54

R410A

C/D

I class

IPX0

IP24

1/4 /1/2

25

15

19

2.5

37

21

 4.5

39

570x570x260

647x647x50

760x285x590

655x655x290

715x715x123

887x355x645

7,03

7,62

2450

2500

220~240/50

11.2/11.4

1327/1114/871

3200

49/46/40

59

R410A

C/D

I class

IPX0

IP24

3/8 /5/8

25

15

24

5

48

30

8

54.5

840x840x230

950x950x55

842x324x695

900x900x250

1035x1035x90

965x395x755

17,58

19,05

6258

6500

380~420/50

10.8/11.2

1800/1480/1280

6800

52/48/43

63

R410A

C/D

I class

IPX0

IP24

1/2 /3/4

50

25

32

5

99

36

8

109

840x840x300

950x950x55

900x340x1167

900x900x320

1035x1035x90

1032x443x1307

14,07

15,24

4885

4948

380~420/50

8.4/8.5

1545/1354/1187

6800

52/48/43

63

R410A

C/D

I class

IPX0

IP24

1/2 /3/4

50

25

28,7

5

97

32.6

8

107

840x840x300

950x950x55

900x340x1167

900x900x320

1035x1035x90

1032x443x1307

10,55

11,72

3850

3650

380~420/50

6.8/6.5

1545/1354/1187

5000

51/47/42

63

R410A

D/C

I class

IPX0

IP24

1/2 /3/4

30

20

28,7

5

85

32

8

93

840x840x300

950x950x55

990x354x966

900x900x320

1035x1035x90

1120x435x1100

Indoor unit
Outdoor unit
Panel for Indoor unit

H-ALT1-12H-UI029/I
H-ALT1-12H-UI029/O
H-SQ1-CM-UI048

H-ALT1-18H-UI030/I
H-ALT1-18H-UI030/O
H-SQ1-CM-UI048

H-ALT1-24H-UI031/I
H-ALT1-24H-UI031/O
H-SQ1-ST-UI049

H-ALT1-60H-UI034/I
H-ALT1-60H-UI034/O
H-SQ1-ST-UI049

H-ALT1-48H-UI033/I
H-ALT1-48H-UI033/O
H-SQ1-ST-UI049

H-ALT1-36H-UI032/I
H-ALT1-36H-UI032/O
H-SQ1-ST-UI049
