EKUHWBB + EKUHW2WB + EKHWSU150-300B3V3
Domestic hot water tank with option kit for air to water heat pump
system
4P344370-1 – 2013.03
Installation manual
12
Symptom 4: Continuous water discharge
Technical specifications
Domestic hot water tank specifications
P
OSSIBLE
CAUSES
C
ORRECTIVE
ACTION
Cold water inlet pressure.
Check the pressure reducing valve.
Replace the pressure reducing valve
if the measured pressure is >2.1 bar.
Temperature and pressure relief
valve.
Check and reset button.
The expansion relief valve is not
functioning properly.
Check for correct operation of the
pressure relief valve by turning the
red knob on the valve counter
clockwise:
• If you do not hear a clacking
sound, contact your local dealer.
• In case the water keeps running
out of the unit, close both the
water inlet and outlet shut-off
valves first and then contact your
local dealer.
EKHWSU150B3V3
EKHWSU200B3V3
EKHWSU300B3V3
Storage capacity
150 l
200 l
285 l
Hot water capacity
(a)
136 l
175 l
252 l
Overall dimensions (Ø×H)
580×1015 mm
580×1265 mm
580×1715 mm
Booster heater
-
power supply
230 V 50 Hz 1P
230 V 50 Hz 1P
230 V 50 Hz 1P
-
running current
13 A
13 A
13 A
-
capacity
3 kW
3 kW
3 kW
Operating pressure / set pressure of the pressure
reducing valve
3.5 bar
3.5 bar
3.5 bar
Maximum primary working pressure (heating side)
2.5 bar
2.5 bar
2.5 bar
Expansion vessel pre-charge pressure
2.5 bar
2.5 bar
2.5 bar
Preset opening pressure of expansion relief valve
8 bar
8 bar
8 bar
Maximum design pressure
10 bar
10 bar
10 bar
Preset opening temperature of temperature and
pressure relief valve
90~95°C
90~95°C
90~95°C
Set opening pressure of temperature
and pressure relief valve
10 bar
10 bar
10 bar
Temperature and pressure relief valve replacement
part number
302810P
302810P
302810P
Connections
3/4" FBSP
(b)
3/4" FBSP
(b)
3/4" FBSP
(b)
Weight
-
empty
38 kg
46 kg
60 kg
-
when full
188 kg
246 kg
345 kg
Mounting
Wall or floor
Floor
Floor
Supply temperature time
(a)
(c)
41.98 min
31.96 min
46.08 min
Maximum water supply pressure
8 bar
8 bar
8 bar
Re-heat time
(a)
(d)
41.61 min
31.82 min
45.68 min
Maximum operating temperature of the heating fluid
(a)
80°C
80°C
80°C
Pressure drop through the primary heater
(a)
20 kPa
50 kPa
50 kPa
Primary heating power input(d)
(a)
10.1 kW
17.3 kW
17.1 kW
Primary flow rate
(a)
15 l/min
15 l/min
15 l/min
Standing heat losses
(a)
1.55 kWh/24h
1.77 kWh/24h
2.19 kWh/24h
Corrosion protection: anode
Aluminium
Aluminium
Aluminium
(a) Values according to EN12897.
(b) FBSP = Female British Standard Pipe.
(c) The time it takes to increase the temperature from 15°C to 60°C.
(d) The time it takes to increase 70% of the vessel back up to 60°C.
