Installation manual
44
EKCBX/H008BBV3
Unit for air to water heat pump system
4PW66983-1C – 08.2011
17. D
ISPOSAL
REQUIREMENTS
Dismantling of the unit, treatment of the refrigerant, of oil and of other
parts must be done in accordance with the applicable legislation.
18. U
NIT
SPECIFICATIONS
Technical specifications
Electrical specifications
(*)
European/International Technical Standard setting the limits for voltage
changes, voltage fluctuations and flicker in public low-voltage supply
systems for equipment with rated current
≤
75 A.
(**) European/International Technical Standard setting the limits for harmonic
currents by equipment connected to public low-voltage systems
with input current >16 A and
≤
75 A per phase
(***) System impedance
P4
Electric component failure
Contact your local dealer.
PJ
Failure of capacity setting
Contact your local dealer.
U0
Refrigerant failure (due to
refrigerant leak)
Contact your local dealer.
U2
Main circuit voltage failure
Contact your local dealer.
U3
Underfloor heating screed
dry-out program has been
stopped by another error, or by
pushing operation off button, or
by power failure.
The error can only be reset in
the test mode as follows:
First, press the
z
button 4 times
so the
t
icon will be
displayed. Then press the
y
button 1 time. Finally push the
z
button to exit the test mode.
Notes:
• In this case [F-09] "Latest action
number executed" will contain
the latest action number
executed.
• [F-08] "Underfloor heating
screed dry-out program enabled
(1)/disabled (0)" is always
cleared to 0 (disable). This
means that in case a second
time a "Underfloor heating
screed dry-out program" must be
started, [F-08] needs to be set
again.
U4
Communication failure
Contact your local dealer.
U5
Communication failure
Contact your local dealer.
U7
Communication failure
Contact your local dealer.
UA
Field settings related to unit type
selection not confirmed yet.
Set correct unit type according to
the table and steps as explained
in
.
Error
code
Failure cause
Corrective action
EKCBX008BBV3
EKCBH008BBV3
Dimensions H x W x D
(mm)
390 x 412 x 100
Weight
(kg)
6
Indoor unit
EKCBX008BBV3
EKCBH008BBV3
Power supply
(a)
(a) Above mentioned power supply is for the booster heater (EKW* option) and
backup heater kit (EKMBUH).
The switch box of the EKCB indoor unit is supplied via the outdoor unit.
The EKMBUH heater kit can be installed as a single step 3 kW heater or a 2 step
6 kW heater, for detailed information, refer to the heater kit installation manual.
• Phase
1~
• Frequency
(Hz)
50
• Voltage
(V)
230 (±10%)
• Running current (heater kit)
(A)
26
• Z
max
(heater kit + booster
heater (EKHWS* models))
(Ohm)
0.29
• Running current (heater kit +
booster heater (EKHWS* models)
• EK*V3
(A)
39 (26 + 13)
• EK*Z2
(A)
33.5
• Minimum S
SC
value
(b)
(b) In accordance with EN/IEC 61000-3-11
, it may be necessary to consult the
distribution network operator to ensure that the equipment is connected only to a
supply with Z
sys
≤
Z
max
• EK*V3
(kVA)
(c)
(c) Equipment complying with EN/IEC 61000-3-12
• EK*Z2
(kVA)
Operation range
• Ambient temperature
(°C)
5~35
