English

12

First installation

1  Remove all packaging material from the machine.
2  Place the machine on a table or work surface away from the tap, from the sink and from sources of
heat.

Note:

 leave at least 15 cm of vacant space at the top, at the rear and at the sides of the machine

(fig. 1).

3  Remove the water tank lid, then remove water tank from the machine (fig. 2).
4  Rinse the water tank. Fill the tank with fresh water up to the maximum level (MAX) graduation mark
(fig. 3).
5  Place the water tank in the machine once again and push it downwards until the reference marks
are visible (fig. 4).
6  Place the water tank lid on the machine.

Priming the circuit

When using the machine for the first time, or after the machine has not been used for more than 2
weeks, proceed as follows:
1  Place a container under the pannarello with the selection knob at the central standby position
(fig.8). Turn the hot water/steam knob counter-clockwise (fig. 5).
2  Insert the plug into the wall power socket and set the power button on "I" to switch on the machine
(fig. 6).

-

The power-on light will come on.

3  Turn the selection knob up to the coffee position (fig. 7).

-

Hot water will flow out from the pannarello.

Note:

 To empty the container when full, move the selection knob to stand-by position (fig.8) and

turn the hot water/steam knob clockwise to stop dispensing.

4  Once the water tank is empty, move the selection knob back to the central standby position (fig. 8).
5  Turn the hot water/steam knob clockwise. Remove the container (fig. 9).

Note:

 when using the machine normally, to prime the circuit you only need to dispense just one

cup of water from the pannarello.

Manual rinse cycle

Note:

 the circuit needs to be primed should the the tank be completely empty.

1  Rinse the water tank. Fill the tank with fresh water up to the maximum level (MAX) graduation mark
(fig. 3).
2  Place the water tank in the machine once again and push it downwards until the reference marks
are visible (fig. 4).
3  Place a container under the classic pannarello and turn the hot water/steam knob counter-
clockwise (fig. 5).
4  Turn the selection knob up to the coffee position (fig. 7).

-

Let the machine dispense water until the water tank is empty.

5  Move the selection knob back to the standby position (fig. 8) and turn the steam/hot water knob
clockwise.
6  Fill the tank with fresh water up to the maximum level (MAX) graduation mark.
