i

Individualization and dat

a tr
ansf
er

Pag

e 51

uSb: Available advertising images

Advertising images

Product images

Screen saver

load product images with Drag & Drop 0 to 100

load images

Manage my images

26 %

50

0

Free memory (Mb):

1.7 Create directory structure

1.6 eject uSb stick

1.3 Advertising images

1.5 Screen saver

1.2 back up images

1.4 Product images

1.1 load images

loading or clearing my images

• The upload process is the same for all images.
• The images on the uSb stick must be present in the required

folder structure, have the correct data format and the correct

size,

see p. 50.

1 Manage images

1.2 back up images

1.1 load images

1.3 Advertising images

1.6 eject uSb stick

1.4 Product images

1.7 Create directory structure

1.5 Screen saver

Desired action

Menu item

Information / Instruction

loading images to the
machine

1.1 Load images

• Insert a uSb stick with the required directory structure.
• Select the image type.
• Select the images that you wish to load onto the machine using Drag&Drop and

press

Save

.

Saving images from the
machine

1.2 Back up images

• Insert a uSb stick.
• Select the image type.
• Save individual images or all images to the uSb stick.

Clearing images

1.3 Advertising images
1.4 Product images
1.5 Screen saver

• Open the desired menu.
• Select the images that are no longer needed and delete them by tapping the

Clear

button.

back

Save

load all
