Franke A800 FM - Инструкция по эксплуатации - Страница 22

Ins

tallation and t

ec

hnical dat

a

Pag

e 20

FoamMaster Su12 (Twin)

(optional)

Weight

Approx. 26 kg

Width/Depth/Height

340 mm/475 mm/540 mm

Device type

FCS4048

Milk container

5 l

electrical connection

eu

220 – 240  V 1l n Pe 50/60  Hz
Su05 FM 1.95 – 2.3 kW
Su05 MS Current  consumption:  0.72 A

uSA

120  V 1l n Pe 60 Hz
Su05 FM 1.44 kW
Su05 MS Current  consumption:  1.5 A

electric cable

1800 mm

Ambient conditions

Humidity: max. 80%
Ambient  temperature:  10 – 32 °C

Coolant

R134a  /40 g

Climate class

n (temperate climate)

noise emission

< 70  db (A)

Cooling temperature

2.0 - 5.0 °C

empty weight

Su05 MS 16.1 kg   (with base 17.6 kg)

Su05 FM 23.0 kg   (with base  24.5 kg)

Width/Depth/Height

270 mm/474 mm/540 mm

under-counter refrigeration unit uT12 (Twin)

(optional)

Chill & Cup

(optional)

Payment system AC

(option)

base refrigeration unit uC05

(optional)

Refrigeration unit Ke200

(optional)

Flavor Station FS30

(option)

Weight

Approx. 26 kg

Width/Depth/Height

320 mm/467 mm/547 mm

Weight

Approx. 29 kg

Width/Depth/Height

320 mm/471 mm/502 mm

Device type

FCS4056

electrical connection

85–264 V 1l n Pe

Weight

Approx.  18 kg

Wastewater tank/Drip tray

3 l

Width/Depth/Height

200 mm/451 mm/542 mm

Weight

Approx. 27 kg

Width/Depth/Height

320 mm/646 mm/238 mm

Weight

Approx.13 kg

Width/Depth/Height

225 mm/453 mm/330 mm

Device type

FCS4055

Capacity

up to 3 varieties of syrup

electrical connection

220–240  V 1l n Pe 75 W 50/60 Hz   
Fuse: 10 A

electric cable

1800 mm

Weight

Approx. 17 kg

Width/Depth/Height

200 mm/451 mm/545 mm

Su05 MS

(optional)

Device type

FCS4054

Capacity

up to 120 cups (depending on cup size)

electrical connection

220 - 240 V 1l n Pe 120 W 50/60 Hz   
Fuse: 10 A

Weight

Approx. 20 kg

Width/Depth/Height

270 mm/475 mm/540 mm

Cup warmer CW

(optional)
