9

ENGLISH

(For further information, visit the www.powerquality.eaton.com site or contact after-sales support.)

Problem

Diagnostic

Solution

1

• The battery backup outlets

19

are not supplied with power.

• Button

6

is not lighted on.

• Press button

6

and check that

it turns green.

2

• The connected devices are not

supplied when AC power fails.

• The devices are not connected

to the battery backup outlets

19

.

• Connect the devices to the

battery backup outlets

19

.

3

• AC power is available, but the

UPS operates on battery power.

• Circuit breaker

20

, located at

the rear of the UPS, has been

tripped by an overload on the

UPS output.

• Disconnect excess equipment

and reset the circuit breaker

20

by pressing the corresponding

button.

4

• Green button

6

flashesand

audible alarm beeps every 3

seconds.

• The UPS battery backup outlets

19

 are overloaded.

• Disconnect excess equipment

connected to the battery backup

outlets

19

 .

5

• Fault sign

12

 appear on the LCD

panel and audible alarm beeps

continuously.

• A fault has occurred on the UPS.

The battery backup outlets

19

 are

no longer supplied.

• Call after-sales support.

6

• Green LED

8

 is off and the

filteredoutlets

18

 are supplied.

• Surge protection is no longer

provided.

• Call after-sales support.

7

• EcoControl outlets keep powered

when main application (Master

outlet) is stopped.

• EcoControl function is not

activated or not properly set.

• Activate or set properly

EcoControl function using the

software provided with the

product.

7. Troubleshooting

AC-power disturbance

•   If AC power is disturbed or fails, the UPS continues to operate on battery power.

Button

6

flashesgreen.Innormalmode,theaudiblealarmbeepseverytenseconds,

then every three seconds when the end of battery backup time is near. In silent mode,

the audible alarm simply beeps once when the UPS transfers to battery power.

•   If the power outage lasts longer than the battery backup time, the UPS shuts down

and automatically restarts when power is restored. Following a complete discharge, a

few hours are required to recharge the battery back to full backup time.

Surge protection:

All outlets include surge protection.

Shutdown of the battery backup outlets

19

Press button

6

 for more than two seconds.
