5

Technical characteristics

Performances tested according to IEC 61643-1 (class 3) standard for 8/20 µs surge wave

(*) Warning:

Output cables should not exceed 10 m length.

Ellipse PRO

650

850

1200

1600

• UPS

power

650 VA  /

400 W

850 VA  /

510 W

1200 VA  /

750 W

1600 VA  /

1000 W

•

Nominalinputvoltage

165 V - 264 V, adjustable to 150 V - 284 V

• Input frequency

50/60 Hz (46 - 70 Hz working range)

•  Voltage/frequency of battery backup

outlets

19

 in battery mode

220 V / 230 V / 240 V +15 % -20 % (50/60 Hz ± 1 Hz)

• Total output current for all outlets

10 A max

•  Output current of battery backup

outlets

19

3 A max

3.6 A max

5.5 A max

7.3 A max

• Leakage current

0.4 mA

• Input protection

10 A resettable circuit breaker

• Transfer time

5 ms typical

• Telephone/Data surge protection

Tel,ISDN,ADSL,Ethernet

• Sealed lead-acid battery

12 V,  7 Ah

12 V,  9 Ah

2x12V, 7 Ah

2x12V, 9 Ah

• Automatic battery test

Once a week

• Average battery life

4 years typical, depending on temperature and number of discharge

cycles

• Operating temperature

0 to 35 °C

• Storage temperature

-25 °C to +55 °C

• Operating relative humidity

0 to 85 %

• Operating elevation

0 to 2000 m

• Safety standards

IEC62040-1,CEcertified

• Electromagnetic compatibility standards

IEC 62040-2, C1*

• Warranty

3 years

• Dimensions (mm/

inch

)

260 x 82 x 285 /

10.24 x 3.23 x 11.22

275 x 82 x 390 /

10.83 x 3.23 x 15.35

• Weigth (kg/

lb

)

6.9 /

15.2

7.3 /

16.1

9.7 /

21.4

11.5 /

25.4

AC input source protection, Ellipse PRO:

650

850

1200

1600

• Uoc (common mode / differential mode)

6 kV / 2 kV

• Up (common mode / differential mode)

1.8 kV / 1 kV

• In

3 kA

Dielectric isolation

• AC Ground

1500 Vac, 50 Hz

• AC  / TEL

3000 Vac, 50 Hz

• Tel / Ground

1000 Vac, 50 Hz

Temporary overvoltage (TOV)

• Uc

250 Vac

• Ut

430 Vac

Energy dissipation

405 Joules
