36

1. Loosen the screws

❶

and

❸

at

the hinge of the case section, and
push the door to the right to
disconnect. (See Figure 20)

2. Completely loosen the screws

❶

and

❸

, and then fix them at the

opposite side loosely. (See Figure
20)

3. Loosen the screws

❷

and

❹

fixed to the door to disconnect
the hinge.

4. Move the disconnected hinge to

the diagonal direction as shown
at Figure 21, turn it 180°, and
then fix the hinge to the door.

5. Align the door hinge with the

screw fixed at the case, and push
from the left to the right.

6. Adjust the top/bottom/left/right

gap of the refrigerator door to
remove tilting, and then secure
the screws.

7. After fixing the hinge, insert the

cap screws

⑬

(two spots) at the

opposite holes of the hinge.

※

Before installing, change the door to work.

6. Procedure to install

6) Changing the opening direction of the refrigerator door

1

2

(Figure 20)

(Figure 21)
