5.9 Information system

Fig. 3

(1) Ready-made meals, ice

cream

(4) Sausages, bread

(2) Pork, fish

(5) Game, mushrooms

(3) Fruit, vegetables

(6) Poultry, beef/veal

The  figures  indicate  the  storage  time  in  months  for  several

types  of  frozen  food  in  each  case.  Storage  times  given  are

guide times.

5.10 Cold storage accumulators

The  cold  storage  accumulators  prevent  the  temperature  from

rising too fast in the event of power failure.

5.10.1 Using cold storage accumulators

u

Freeze  and  store  the  cold  storage  accumu-

lators  in  the  ceiling  of  the  freezer  compart-

ment (appliances without No-Frost module).

With  the  top  drawer

removed:

u

to insert cold storage accu-

mulators:

slide

cold

storage  accumulator  into

the  top  back  of  the  freezer

compartment  ceiling  and

snap into place at the front.
With  the  top  drawer

removed:

u

to  remove  cold  storage

accumulators:  take  hold  of

the  cold  storage  accumu-

lator  at  the  side  and  press

it down for removal.

6 Maintenance

6.1 Manual defrosting

After a long period of operation, a layer of frost or ice can build

up inside the appliance.
The  layer  of  frost  or  ice  builds  up  faster  if  the  appliance  is

opened  often  or  if  the  food  is  warm  when  placed  inside.

However,  a  thick  layer  of  ice  will  increase  the  appliance‘s

energy  consumption.  You  should  therefore  defrost  the  appli-

ance regularly.

CAUTION

Risk of injury and damage as a result of hot steam!

u

Do not use electric heaters or steam cleaners, naked flames

or defrosting sprays for defrosting.

u

Do not remove ice using sharp instruments.

u

Switch on SuperFrost one day before defrosting.

w

The frozen goods are provided with a "cold reserve".

u

Switch off the appliance.

w

The temperature display goes out.

u

Pull out the power plug or switch off the fuse.

u

Place cold storage accumulators on top of the frozen food.

u

If  possible,  put  the  frozen  goods  in  the  freezer  drawer,

wrapped  in  newspaper  or  a  blanket,  and  store  in  a  cool

place.

u

Place  a  pan  with  hot,  not  boiling

water on a middle shelf.

-or-

u

Half-fill  the  two  lower  drawers  with

lukewarm  water  and  put  them  in  the

appliance.

w

Defrosting is speeded up.

w

Defrost water is collected in the drawers.

u

Leave the door of the appliance open while defrosting.

u

Remove detached pieces of ice.

u

Pay  attention  that  the  defrost  water  does  not  run  into  the

kitchen unit.

u

If  necessary,  pick  up  defrost  water  several  times,  using  a

sponge or cloth.

u

Clean the appliance (see 6.2) and rub dry.

6.2 Cleaning the appliance

Before cleaning:

CAUTION

Risk of injury and damage as a result of hot steam!

Hot steam may damage the surfaces and cause burns.

u

Do not use any steam cleaners!

NOTICE

Incorrect cleaning damages the appliance!

u

Do not use cleaning agents in concentrated form.

u

Do not use any scouring or abrasive sponges or steel wool.

u

Do  not  use  any  cleaning  agents  containing  sand,  chloride,

chemicals or acid.

u

Do not use chemical solvents.

u

Do not damage or remove the type plate on the inside of the

appliance. It is important for the customer service.

u

Do  not  pull  off,  bend  or  damage  cables  or  other  compo-

nents.

u

Do  not  allow  any  cleaning  water  to  enter  the  drain  channel,

ventilation grille or electrical parts.

u

Empty the appliance.

u

Pull out the plug.

- Use  soft  cleaning  cloths  and  a  multi-purpose

cleaning agent with neutral pH value.

- Only  use  food  compatible  cleaning  and  care

agents on the inside of the appliance.

u

Regularly clean ventilation grilles.

w

Dust deposits increase energy consumption.

Interior:

u

Clean  the  plastic  surfaces,  outside  and  inside,  by  hand

using lukewarm water and a little washing-up liquid.

Items of equipment:

u

Clean items of equipment by hand with lukewarm water and

a little washing-up liquid.

After cleaning:

u

Wipe dry the appliance and items of equipment.

u

Connect the appliance and switch it on again.

u

Switch on SuperFrost (see 5.5) .

When the temperature is sufficiently cold:

u

Put the food back inside.
