Do not install the appliance without assistance.
Standard  EN  378  specifies  that  the  room  in  which  you  install

your  appliance  must  have  a  volume  of  1  m

2

  per  8  g  of  R  600a

refrigerant used in the appliance. If the room in which the appli-

ance  is  installed  is  too  small,  a  flammable  gas-air  mixture  may

form  in  the  event  of  a  leakage  in  the  refrigeration  circuit.  The

quantity of refrigerant used in your appliance is indicated on the

type plate on the inside of the appliance.

WARNING

Fire hazard due to dampness!

If  live  parts  or  the  mains  lead  become  damp  this  may  cause

short circuits.

u

The appliance is designed for use in enclosed areas. Do not

operate  the  appliance  outdoors  or  in  areas  where  it  is

exposed to splash water or damp conditions.

WARNING

Fire hazard due to refrigerant!

The  refrigerant  R  600a  is  environmentally  friendly  but  flam-

mable. Escaping refrigerant may ignite.

u

Do not damage the piping of the refrigeration circuit.

WARNING

Fire hazard and danger of damage!

u

Do  not  place  appliances  emitting  heat  e.g.  microwaves,

toasters etc. on the appliance!

WARNING

Blocked ventilation openings pose a risk of fire and damage!

u

Always  keep  the  ventilation  openings  clear.  Always  ensure

that the appliance is properly ventilated!

u

Detach the connecting cable from the rear of the appliance,

removing  the  cable  holder  at  the  same  time  because  other-

wise there will be vibratory noise!

After installation:

u

Remove all transit supports.

u

Unscrew  the  red  transport

lock.  Close  the  vacated

retaining  hole  using  the

stopper (60).

u

Dispose of packaging material (see 4.3) .

For Side-by-Side installation, freezer and refrigerator side by

side:

u

Always  install  the  freezer  on  the  right  of  the  refrigerator,  as

seen from the front.

w

No condensate forms between the appliances thanks to the

side wall heating system foamed in on the left.

Ventilation is effected by way of the plinth.

Note

u

Clean the appliance (see 6.2) .

If  the  appliance  is  installed  in  a  very  damp  environment,

condensate may form on the outside of the appliance.

u

Always see to good ventilation at the installation site.

4.3 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.4 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.

u

Check the electrical connection.

u

Plug in the power plug.

4.5 Switching on the appliance

u

Press On/Off button

 Fig. 2 (1).

w

The  appliance  is  switched  on.  The  temperature  display  and

the  alarm  button  flash  until  the  temperature  is  sufficiently

cold.

5 Control

5.1 Temperature alarm

The audible alarm sounds if the freezer temperature is not cold

enough.
The alarm button flashes at the same time.
The cause of the temperature being too high may be:

-

warm fresh food was placed inside

-

too much warm ambient air flowed in when rearranging and

removing food

-

power failure for some time

-

the appliance is faulty

The  audible  alarm  is  automatically  silenced,  the  alarm  button

Fig.  2  (5)  goes  out  and  the  temperature  display  stops  flashing

when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).

Note

Food may be spoilt if the temperature is not cold enough.

u

Check the quality of the food. Do not consume spoiled food.

Control

4
