5.1.1 Muting the temperature alarm

The  audible  alarm  can  be  muted.  When  the  temperature  is

sufficiently cold again, the alarm function is active again.

u

Press alarm button

 Fig. 2 (5).

w

The audible alarm is silenced.

5.2 Freezing food

The  rating  plate  indicates  the  maximum  quantity  of  fresh  food

you  can  freeze  within  24  hours  (see  Appliance  at  a  glance)

under "Freezing capacity ... kg/24h".
The maximum load of frozen food for the drawers is 25 kg each

and for the shelves 35 kg each.
A  vacuum  is  generated  after  the  door  is  closed.  After  closing

the door, wait for about 1 minute and then it opens more easily.

CAUTION

Risk of injury due to broken glass!

Bottles  and  cans  containing  drinks  may  burst  when  being

frozen. This applies particularly to sparkling drinks.

u

Do not freeze bottles and cans containing drinks!

In  order  that  the  food  is  rapidly  frozen  through  to  the  core,  do

not exceed the following quantities per pack:
- Fruit, vegetables up to 1 kg

- Meat up to 2.5 kg

u

Pack  the  food  in  portions  in  freezer  bags,  reusable  plastic,

metal or aluminium containers.

5.3 Thawing food

- at room temperature

- in a microwave oven

- in a conventional or fan oven

u

Food  once  thawed  should  be  re-frozen  only  in  exceptional

cases.

5.4 Setting the temperature

Temperature setting to be recommended: -18 °C
The  temperature  can  be  changed  continuously.  Once  the

-32 °C setting is reached, it starts again with -15 °C.

u

To  access  temperature  adjustment:  press  setting  button

Fig. 2 (2) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display.

u

Press  the  setting  button

  Fig.  2  (2)  the  number  of  times

needed  until  the  required  temperature  shines  in  the  LED

display.

Note

u

Long  pressing  of  the  setting  button  sets  a  slightly  colder

value  within  a  small  temperature  range  (e.g.:  between

-15  °C  and  -18  °C).  The  LED  of  the  next  lower  temperature

range then shines in the temperature display.

5.5 SuperFrost

With  this  function  you  can  freeze  fresh  food  quickly  through  to

the  core.  The  appliance  operates  with  maximum  refrigeration.

The noise of the refrigeration unit may be temporarily louder as

a result.
In  addition,  frozen  food  already  in  storage  is  given  a  "cold

reserve".  The  food  stays  frozen  longer  as  a  result  when  you

defrost the appliance.
The  maximum  amount  of  fresh  food  which  can  be  frozen  in  24

h  is  indicated  on  the  type  plate  under  "freezing  capacity  ...  kg/

24h".  This  amount  varies  according  to  the  model  and  climate

rating.
You do not have to activate SuperFrost in the following cases:

-

when placing frozen food in the freezer

-

when freezing up to about 2 kg fresh food daily

5.5.1 Freezing with SuperFrost

u

Briefly press the SuperFrost button

 Fig. 2 (4).

w

The SuperFrost button shines.

w

The  freezer  temperature  drops,  the  appliance  operates  with

the maximum refrigerating capacity.

In case of a small amount of food to be frozen:

u

wait about 6 h.

u

Place the fresh food in the bottom drawers.

In  case  of  the  maximum  amount  of  food  to  be  frozen  (see

type plate):

u

wait about 24 h.

u

Place food in the drawers.

w

SuperFrost is automatically deactivated after about 65 h.

w

The SuperFrost button is dark.

w

The  temperature  range  set  for  the  normal  mode  shines  in

the temperature display.

w

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.6 Drawers

u

To store frozen food directly on the shelves: pull the drawer

forwards and lift it out.

5.7 Shelves

u

To  remove  the  shelf:  lift  up  at  the  front

and pull out.

u

To  put  the  shelf  back:  simply  push  in  as

far as it will go.

5.8 VarioSpace

Apart from being able to remove

the  drawers,  you  can  also

remove  the  shelves,  creating

space  for  large  items  of  frozen

food. Poultry, meat, large pieces

of  game  and  high  bakery  prod-

ucts  can  be  frozen  in  one  piece

and prepared.

u

The  maximum  load  of  frozen

food  for  the  drawers  is  25  kg

each  and  for  the  shelves

35 kg each.
