In order to take off the appliance cover:

u

Remove the screws

 Fig. 7 (2) from the rear side.

u

Raise the cover up at the back, slide forward and lift up and

off the appliance.

4.5 Disposing of packaging

WARNING

Danger of suffocation due to packing material and plastic film!

u

Do not allow children to play with packing material.

The packaging is made of recyclable materials:

-

corrugated board/cardboard

-

expanded polystyrene parts

-

polythene bags and sheets

-

polypropylene straps

-

nailed wooden frame with polyethylene panel*

u

Take the packaging material to an official collecting point.

4.6 Connecting the appliance

NOTICE

Risk of damage to the electronic control system!

u

Do  not  use  stand-alone  inverters  (conversion  of  d.c.  to  a.c./

three-phase) or energy saving plugs.

WARNING

Fire and overheating hazard!

u

Do not use extension cables or multiple socket outlets.

The  type  of  current  (alternating  current)  and  voltage  at  the

installation site have to conform with the data on the type plate

(see Appliance at a glance).

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.  It  must  be  outside  the  area  of  the  rear  of  the

appliance.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

Put  the  appliance  into  operation  about  2  hours  before  first

loading food to be frozen.

u

Turn  the  temperature  control

 Fig. 3  (1) to the right, from the

0 setting to point 3.

w

The interior light is on.

5 Control

5.1 Refrigerator compartment

The  natural  circulation  of  air  in  the  refrigerator  compartment

results  in  zones  differing  in  temperature.  It  is  coldest  directly

above the vegetable drawers and at the rear wall. It is warmest

at the top front of the compartment and in the door.

5.1.1 Food refrigeration

u

Store  perishable  food  such  as  ready-to-serve  dishes,  meat

products  and  sausages  in  the  coldest  zone.  Place  butter

and preserves in the upper area and in the door (see Appli-

ance at a glance).

u

Use  recyclable  plastic,  metal,  aluminium  and  glass

containers and cling film for wrapping.

u

Always  store  liquids  and  food  which  is  subject  to  odour  or

taste transfer in closed containers or cover them.

u

Foods  which  give  off  a  large  amount  of  ethylene  gas  and

delicate  foods,  such  as  fruit,  vegetables,  salad,  should

always be stored separately or wrapped so as not to reduce

the  storage  life;  e.g.  do  not  store  tomatoes  together  with

kiwis or cabbage.

u

Do  not  store  food  too  close  together  to  enable  good  air

circulation.

u

To  safeguard  bottles  from  tipping  over:  move  the  bottle

holder.

5.1.2 Setting the temperature

The  temperature  can  be  set  between  1  (warmest  temperature,

minimum  cooling  performance)  and  7  (coldest  temperature,

maximum cooling performance).
The  middle  control  setting  is  recommended,  then  a  middle

temperature  of  approx.5  °C  is  established  in  the  refrigerator

compartment.
To ensure ideal temperatures for storing frozen foods, a setting

of  "4"  to  "7"  on  the  temperature  controller  is  recommended.

Selecting  "7"  makes  it  possible  to  achieve  temperatures  under

0 °C in the coldest part of the fridge compartment.
An  average  temperature  of  approx.  –18  °C  is  then  established

in the freezer compartment

u

Turn the temperature control

 Fig. 3 (1).

At low room temperatures of 18 °C or lower:

u

Press the Cool-Plus switch

 Fig. 3 (2).*

w

The  deep  temperatures  in  the  freezer  compartment  are

ensured.*

w

The  appliance's  interior  lighting  is  lit  on  a  dim  setting  even

when the door is closed.*

Note*

u

At normal room temperatures, in excess of 18 °C, the Cool-

Plus switch should be turned off, as it is not required.

The temperature depends on the following factors:
- the door opening frequency

- the  room  temperature  at  the  site  where  the  appliance  is

installed

- the type, temperature and quantity of frozen food

u

Adjust the temperature as needed, using the control.

5.1.3 Relocating the shelves

The  shelves  have  stops  preventing  them  from  being  uninten-

tionally pulled out.

u

Lift the shelf and draw it out forwards.

u

Insert  shelf  with  the  raised  edge

pointing upwards at the back.

w

The food does not freeze onto the rear

wall.

5.1.4 Using the sectioned shelf

Fig. 8

u

The glass shelf with stop face (2) has to be at the back.
