12

Freezer

compartment*

Do not use any elec-

trical heating or steam

cleaning appliances,

defrosting sprays, open

flames or metal objects

to remove ice. Risk of

injury and damage to the appliance.

To accelerate the defrosting process, put a pan with warm,

not boiling water into the compartment.

How to defrost:

W

  Switch off the appliance: Disconnect from the mains or

-  Turn the temperature setting to the “0” position.

W

 Remove frozen goods, put into newspaper or blankets and

stored in a cool place.

W

 Leave the compartment and appliance door open during the

defrosting process.

W

  Collect defrosting water with a sponge or cloth. Then

clean the appliance.

Cleaning

W

  Before cleaning, always switch off the app-

liance. Disconnect from the mains or un-screw

or switch off the fuse.

W

  Clean the outer walls, inside and appliance by

hand with lukewarm water and a little detergent. Because

of the risk of injury and damage to the appliance, steam

cleaning equipment should not be used.

  Never use abrasive or scouring sponges. Do not use con-

centrated cleaning agents and never use abrasive or acid

cleaners or chemical solvents.

-  We recommend using a soft cloth and an all-purpose clea-

ner with a neutral pH value. Only use food safe cleaning

materials inside the appliance.

-  Ensure that no cleaning water penetrates into the electri-

cal components, drain gulley* or ventilation grilles. Wipe

the appliance dry.

-  Do not damage or remove the type plate on the inside of

the appliance. It is very important for servicing purposes.

W

  Clean the

drain hole

 on the rear wall above the vegetable

bins often Fig.

A

, arrow.

  If necessary, clean with a thin object, e.g. a cotton swab or

similar.

W

  Ensure that none of the wires or other components are

dislodged, bent or damaged.

W

  Then connect/switch on the appliance.

If the appliance is to be left switched off

for any length of

time

, empty the appliance, disconnect from the mains, clean

as described above and leave the door open so as to avoid

odours.

6  Troubleshooting

Customer service and type plate

If none of the above causes apply and you cannot

rectify the fault yourself, please contact your near-

est customer service department (see enclosed list

for addresses). State the

type designation

1

, service

number

2

 and

appliance number

3

 as given on the type

plate, so as to ensure rapid, accurate servicing. The type

plate is located inside the appliance on the left-hand side.

5  Defrosting, cleaning

* Depending on model and options

Defrosting

Appliances without freezer compartment defrost automatically.

The moisture occurring at the back wall of the refrigerator

is carried outside the refrigerator into an evaporating dish

through the defrost water channel. The defrost water is

evaporated by the compressor heat - water droplets on the

rear wall depend on function and are completely normal.

W

  At least ensure that the defrost water can always flow out

of through the outlet hole via the vegetable bin to the rear

wall (arrow in Fig. A) unhindered.

Your appliance is designed and manufactured in such a way

as to provide fault.free operation and a long service life.

Nevertheless, if a fault should occur during operation, please

check whether the fault is due to incorrect operation. In this

case we have to charge you for any costs incurred also

within the warranty period.

You can eliminate the following faults yourself by checking

the possible causes:

Fault

possible cause and remedy

Appliance not working

-  Is the appliance switched on properly?

-  Is the mains plug properly inserted in the socket?

-  Is the socket fuse intact?

The interior light does not come on

-  Is the refrigerator compartment switched on?

-  The bulb is defective. Change the bulb as described in

“Interior light”.

Interior light on when Cool-Plus activated:

-  This is necessary from a technical point of view and is

quite normal.

-  To be able to ensure that the Cool-Plus function works

entirely as it should, the defective light bulb should be

replaced as soon as possible.

Loud running noise

-  Is the appliance standing firmly on the floor, or does the com-

pressor cause nearby items of furniture or objects to vibrate?

  If necessary, move the appliance slightly, align by adjusting

the adjustable feet, or move bottles and containers apart.

-  The following are normal:

Flow noises, bubbling or dripping, coming from the

coolant in the refrigerating circuit.

  A soft clicking sound, this always occurs when the refrige-

ration unit (the motor) switches on or off automatically.

  Motor noise; this will be slightly louder for a brief period

when the refrigeration unit switches on. When CoolPlus

is switched on, fresh food is inserted, or when the door is

open for a long time, the refrigerating capacity increases

automatically.

Temperature is not cold enough

-  Is the temperature controller set correctly? (Set colder as

needed).

-  Is the appliance door properly closed?

-  Is there sufficient ventilation?

  Unblock ventilation grill as needed.

-  Is the ambient temperature too hot? (see “Conditions”

section)

-  Has the appliance been open too often or for too long?

-  Wait as needed, whether the required temparture has

been set on its own.
