Liebherr K 3120 Comfort - Инструкция по эксплуатации - Страница 7

Connect  the  appliance  only  with  a  properly  installed

socket outlet with earthing contact. The socket outlet

must be fused with 10 A or higher.
It must be easily accessible so that the appliance can

be quickly disconnected from the supply in an emer-

gency.  It  must  be  outside  the  area  of  the  rear  of  the

appliance.

u

Check the electrical connection.

u

Plug in the power plug.

4.7 Switching on the appliance

u

Press On/Off button

 Fig. 3 (1).

w

The appliance is switched on. The temperature display indi-

cates the set temperature.

5 Control

5.1 Brightness of the temperature

display

You can adjust the brightness of the temperature display to the

light conditions of the room in which the appliance is installed.

5.1.1 Adjusting the brightness

The  backlight  can  either  be  switched  off  or  set  to  one  of  5

levels. The backlight is switched off ex works.

u

Activate  setting  mode  by  pressing  the  SuperCool  button

Fig. 3 (2) for approx. 5 sec.

w

The  menu  symbol

  Fig.  3  (9)  lights  up  and  thebrightness

symbol

 Fig. 3 (7) flashes.

u

Confirm the brightness function: Briefly press the SuperCool

button

 Fig. 3 (2).

w

The brightness symbol

 Fig. 3 (7) shines.

u

Using  the  setting  button

  Fig.  3  (4),  select  either  "off"  or  the

brightness  wanted.  The  more  display  fields  of  the  tempera-

ture display that light up, the brighter it is. If no field is lit up, it

means "off".

u

Confirm by pressing the SuperCool button

 Fig. 3 (2).

w

The brightness symbol

 Fig. 3 (7) flashes.

w

The brightness is adjusted to the new value.

u

To  deactivate  the  setting  mode:  Press  the  On/Off  button

Fig. 3 (1).

-or-

u

Wait for 5 minutes.

w

The  brightness  symbol

  Fig.  3  (7)  and  the  menu  symbol

Fig. 3 (9) go out.

w

The  temperature  is  indicated  again  in  the  temperature

display.

5.2 Food refrigeration

Note

The  energy  consumption  increases  and  the  cooling  perform-

ance decreases if the ventilation is inadequate.

u

Always keep the air slits of the fan free.

u

Store  perishable  food  such  as  ready-to-serve  dishes,  meat

products  and  sausages  in  the  coldest  zone.  Place  butter

and preserves in the upper area and in the door (see Appli-

ance at a glance).

u

Use  recyclable  plastic,  metal,  aluminium  and  glass

containers and cling film for wrapping.

u

Always  store  liquids  and  food  which  is  subject  to  odour  or

taste transfer in closed containers or cover them.

u

Foods  which  give  off  a  large  amount  of  ethylene  gas  and

delicate  foods,  such  as  fruit,  vegetables,  salad,  should

always be stored separately or wrapped so as not to reduce

the  storage  life;  e.g.  do  not  store  tomatoes  together  with

kiwis or cabbage.

u

Use the front area of the refrigerator compartment floor only

for  briefly  putting  down  cooled  products,  e.g.  when  rear-

ranging  and  sorting.  However  do  not  leave  cooled  products

there  otherwise  they  may  be  pushed  back  or  tipped  over

when the door is closed.

u

Do  not  store  food  too  close  together  to  enable  good  air

circulation.

u

To  safeguard  bottles  from  tipping  over:  move  the  bottle

holder.

5.3 Setting the temperature

The temperature depends on the following factors:

-

the door opening frequency

-

the  room  temperature  at  the  site  where  the  appliance  is

installed

-

the type, temperature and quantity of frozen food

Temperature setting to be recommended: 5 °C
The temperature can be changed continuously. Once the 1 °C

setting is reached, it starts again with 9 °C.

u

To access temperature adjustment: press the setting button

Fig. 3 (4) once.

w

The  LED  of  the  current  temperature  flashes  in  the  tempera-

ture display.

u

Press  the  setting  button

  Fig.  3  (4)  the  number  of  times

needed  until  the  required  temperature  shines  in  the  LED

display.

Note

u

Long  pressing  of  the  setting  button  sets  a  slightly  colder

value  within  a  small  temperature  range  (e.g.:  between  5  °C

and  7  °C).  The  LED  of  the  next  lower  temperature  range

then shines in the temperature display.

5.4 SuperCool

With SuperCool you switch to the highest cooling performance

to reach lower cooling temperatures. Use SuperCool, to rapidly

cool large amounts of food.
When  SuperCool  is  activated,  the  fan  runs.  The  appliance

operates with maximum refrigeration. The noise of the refriger-

ation unit may be temporarily louder as a result.
The SuperCool function uses slightly more energy.

5.4.1 Cooling with SuperCool

u

Briefly press SuperCool button

 Fig. 3 (2).

w

The SuperCool symbol

 Fig. 3 (6) lights up in the display.

Fig. 11

w

The  cooling  temperature  drops  to  the  coldest  value.  Super-

Cool is activated.

w

SuperCool  is  automatically  deactivated  after  6  to12  hours

The  appliance  continues  to  operate  in  the  energy-saving,

normal mode.

5.4.2 To prematurely deactivate SuperCool

u

Briefly press SuperCool button

 Fig. 3 (2).

w

The SuperCool symbol

 Fig. 3 (6) goes out in the display.

w

SuperCool is deactivated.
